Vlissingen, The Netherlands 12 September 2014 |
 |
 |
 |
||
| Antwerpen 16/05/14 | Antwerpen 16/05/14 | Westerschelde 20/05/15 |
|
Name |
PACIFIC BREEZE |
|
Previous names |
1990 - 03.2003 Pacifik Frigo 03.2003 - 11.2011 Rapa 11.2008 - 11.2010 Pacific Rime |
|
Type |
Refrigerated cargo ship |
|
IMO-number |
8617926 |
|
Call sign |
V7RC6 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
GT |
10.366 t Suez: 11.158 t Panama: 11.696 t |
|
DWT |
Summer: 10.966 t |
|
NT |
4.503 t Suez: 8.665 t panama: 8.935 t |
|
Displacement |
17.536 t laden 6.540 t light |
|
Containers capacity |
66 FEU OR 18 TEU + 60 FEU In hold: 56 FEU 124 TEU On deck: 66 FEU 18 TEU Total: 122 FEU 142 TEU |
|
Reefer plug |
121 |
|
Length |
143,00 m overall 136,02 m between perpendiculars |
|
Breadth |
22,51 m |
|
Draught |
Summer: 9,16 m |
|
Height of signal fore mast |
36,34 m with antenna |
|
Height radar’s mast |
40,00 m |
|
Freeboard |
4.075 mm |
|
Depth |
13,20 m |
|
Speed |
19,0 knots banana laden 19,5 knots in ballast |
|
Built |
1990 |
|
Launch date |
24.06.1989 |
|
Date of completion |
17.04.1990 |
|
Builder |
Brodosplit Shipyard D.O.O. |
|
Yard number |
364 |
|
Hull material |
Steel |
|
Watertight compartments |
7 |
|
Continuous decks |
4 |
|
Main engine |
1x MAN-B&W 6L60 MCE - 2 stroke 6 cylinder 600 x 1.944 mm diesel engine - 8.340 kW / 11.332 hp at 117,0 rpm Built: 1989 Builder: Brodosplit - Tvornica Diesel Motora D.O.O, Split - Croatia |
|
Propelling system |
1x Screw Propeller Solid - aft at 117,0 rpm |
|
Boilers |
1x CHR Foster Wheeler Power 416,00 m² - 6,0 bar |
|
Electric installations |
Power voltage: 450 V Lighting voltage: 220 V Frequency: 60 Hz |
|
Generators |
2x Split MAN-B&W main diesel generatorsets each 900 kVA - 720 kW - 1.060 hp / 440 V 60 Hz |
|
Emergency generator |
1x Diesel generatorset 125 kVA - 100 kW - 151 hp / 440 V 60 Hz at 1.800 rpm |
|
Number of holds |
4 Hold 1: 17,00 x 13,90 x 2,20 m Hold 2&3&4: 18,10 x 8,20 x 2,20 m |
|
Hold capacity |
461.884 ft³ / 13.079,07 m³ |
|
Number of hatches |
7 |
|
Number of compartments |
16 |
|
Cooling sections |
8 |
|
Refrigerating capacity |
326.800 kcal/h |
|
Floorspace |
5.229,52 m² |
|
Pallets |
3.950 |
|
Tank capacities |
Fuel oil: 1.317,7 m³ / 1.202 t Gas oil: 43,0 t Ballast: 1.860,94 m³ Fresh water: 194,39 m³ |
|
Cargo gear |
4x Cranes - SWL 16,0 t or 2x 30,0 t in twin Builder: Hagglund |
|
Manager |
2012 Elysion Shipmanagement ltd. |
|
Previous managers |
2003 Roko Shipmanagement. 2004 Norbulk Shipping U.K. Ltd. 2007 Korkyra Shipping Ltd. 2008 Dobson Fleet Management Ltd. 2010 Solid Shipping Ltd |
|
Operator |
Seatrade Reefer Chartering N.V. |
|
Registered owner |
2010 Kosi Bay Shipping Ltd. Marshall Islands |
|
Previous owners |
1990 Freshwater Marine Inc., Yugoslavia 1994 Mediteranska Plovidba, St. Vincent & the Grenadines 1995 Pacifik Frigo Ltd., St. Vincent & the Grenadines 2003 Starfire Shipping Corp., St. Vincent & the Grenadines 2008 Eurus Navigation Ltd., Marshall Islands |
|
Scrapped |
2017 at Alang - India |
|
Latest data adjustment |
05 June 2017 |
