| Westerschelde 20 March 2020 |
 |
 |
|
| Westerschelde 20/03/20 | Westerschelde 06/11/11 | |
|
Name |
ULTRAMAR |
|
Previous names |
1997 - 13/04/2000 Papagena |
|
Type |
Multi-purpose dry cargo ship. - Equipped for carriage of containers |
|
IMO-number |
9167320 |
|
Call sign |
P3WF9 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
Previous flags |
1997 - 1998 Netherlands Antilles 1998 - 2000 Portugal, Madeira 2000 - 2004 Isle of Man - United Kingdom |
|
GT |
2.820 t |
|
DWT |
Summer: 4.106,3 t |
|
DWCC |
Summer: 3.850 t Winter: 3.750 t |
|
NT |
1.503 t |
|
Number of 20ft containers |
In hold: 111 On deck: 135 Total: 246 |
|
Containers capacity 14 t |
164 |
|
Length |
89,72 m overall 84,98 m between perpendiculars |
|
Breadth |
13,60 m registered |
|
Draught |
Summer: 5,83 m Winter: 5,71 m |
|
Air draft |
31,60 m form keel |
|
Depth |
7,20 m moulded to main deck |
|
Speed |
13,0 knots |
|
Built |
1997 |
|
Keel laid |
27/03/1997 |
|
Launch date |
08/11/1997 |
|
Date of completion |
01/12/1997 |
|
Builder |
Bodewes Shipyards B.V. Werfkade 22 9601 LG Hoogezand The Netherlands |
|
Yard number |
581 |
|
Hull material |
Steel |
|
Hull type |
Double hull Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
4x Transverse to tween deck (32,80 m) |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M25 - 4 stroke 8 cylinder 255 x 440 mm combustion engine 2.400 kW - 3.263 hp at 750 rpm Year of manufacture: 1997 Manufacturer: Krupp Mak Maschinenbau GmbH Falckensteiner Str. 2 24159 Kiel Federal Republic of Germany |
|
Propeller |
1x Controllable pitch propeller - aft at 165 rpm |
|
Electric installations |
2x Plant 380/220 V - 325 kVA 1x Plant 380 V - 330 kVA 1x Plant 380 V - 120 kVA |
|
Shaft generator |
1x 264 kW / 330 kVA |
|
Generators |
2x Scania DSI 11 main diesel generatorsets each 135 kW |
|
Emergency generator |
1x Valmet 620 DSG diesel generatorset 70 kVA |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar |
|
Bow thruster |
1x Fixed pitch thruster 200 kW, forward |
|
Number of holds |
1x Boxshaped narrowing fore and aft 62,88 x 11,00 x 8,35 m |
|
Cargo hold capacity |
Grain: 5.628 m³ / 198.762 ft³ |
|
Number of hatch |
62,90 x 11,00 m |
|
Hatch tye |
Pontoon |
|
Strength |
Hatchcovers: 1,7 t/m² Tweendeck: 3,0 t/m² Tanktop: 15,0 t/m² |
|
Tank capacities |
MGO: 342,4 m³ Ballast water: 1.558,9 m³ potable water: 62,0 m³ |
|
Anchor equipment |
3x Anchors weight each 2.100 kg Chain length: 440,00 m Diameter: 36 mm |
|
Accommodation |
For Captain and Crew of a total 10 persons with heating, ventilation and air-conditioning |
|
Manager |
Hermann Lohmann Schiffahrtsverwaltung GmbH Boschstraße 15, 49733 Haren (Ems) Germany |
|
Previous manager |
Held Bereederungs GmbH & Co., KG Boschstr. 21 49733 Haren/Ems Federal Republic of Germany |
|
Registered owner |
Hermann Lohmann Schiffahrts GmbH & Co. KG MS "ANNA" Care of Hermann Lohmann Bereederungen GmbH & Co., KG Haren (Ems) Germany |
|
Previous owner |
Nordica Schiffahrtsgesellschaft mbH & Co. KG MS "ULTRAMAR", 49733 Haren/Ems - Federal Republic of Germany |
|
Latest data adjustment |
02 August 2023 |
