| Antwerpen 28 December 2012 |
|
 |
|
| Antwerpen 28/12/12 | Antwerpen 16/05/14 |
|
Name |
STAR CARE |
|
Type |
Reefer cargo carrier - Designed for carriage of containers |
|
IMO-number |
9517903 |
|
Call sign |
9V9352 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore |
|
GT |
14.022 t registered |
|
DWT |
12.957 t |
|
NT |
6.724 t registered |
|
Number of 20ft containers |
436 |
|
Length |
162,50 m overall |
|
Breadth |
26,00 m |
|
Draught |
9,72 m |
|
Moulded L x B x D |
150,00 x 26,00 x 14,10 m |
|
Registered L x B x D |
151,49 x 26,00 x 14,10 m |
|
Freeboard |
Summer: 4.421 mm |
|
Depth |
14,10 m moulded |
|
Speed |
22,0 knots |
|
Built |
2009 |
|
Keel laid |
04.10.2008 |
|
Launch date |
27.07.2009 |
|
Date of completion |
13.10.2009 |
|
Builder |
Shikoku Dockyard Co., Ltd. |
|
Yard number |
1050 |
|
Hull material |
Steel |
|
Main engine |
1x MAN-B&W 7S60MC-C - 2 stroke single acting 7 cylinder 600 x 2.400 mm diesel engine - 15.820 kW at 105,0 rpm Manufacturer: Mitsui Engineering & Heavy Machinery Co.Ltd.(B&W), Chiba - Japan |
|
Propellers |
1 |
|
Propeller shaft |
Oil lubrication shaft with monitoring device |
|
Boilers |
1x Auxiliary vertical boiler - 6,9 bar Evaporation: 6,9 t Manufacturer: Osaka Boiler Mfg., Co., Ltd. |
|
Generators |
5x Diesel generatorsets - 6.090 kVA |
|
Min temp |
-32°C |
|
Tank capacities |
Fuel oil: 2.604 m³ Fresh Water: 414 m³ Water Ballast: 2.845 m³ |
|
Manager |
Argo Navis Pte. Ltd. |
|
Operator |
Del Monte |
|
Registered owner |
Grace Ocean Private Limited |
|
Last update |
07.02.2013 |
