Scotia - IMO 8505642

Name

SCOTIA

Previous names

Launch as 18.07.1987 Meise

18.07.1987 - 16.01.2008 Feed Star

16.01.2008 Scotia

Type

General Cargo

IMO-number

8505642

Call sign

V2DO

Flag

Antigua & Barbuda

Previous flag

31.12.1987 Germany

Port of registry

St. John's

GT

1.473 t

DWT

Summer: 2.097 t

NT

726 t

Number of 20ft containers

In hold: 48
On deck: 32

Total: 80

Length

79,10 m overall
74,90 m between perpendiculars

74,80 m registered

Beam

10,90 m overall

Draught

Summer: 3,988 m

Air draft

7,10 m ballast

Forecastle

6,20 m

Poop

14,00 m

Freeboard

500 mm

Depth

4,49 m moulded

Speed

Abt. 9,0 knots

Purpose

Repairs

Built

1987

Keel laid

15.04.1986

Launch Date

19.05.1987

Date of completion

07.1987

Builder

J.H. van Eijk & Zonen Scheepsbouw B.V.
Baanhoek 22
Sliedrecht
The Netherlands

Yard number

361

Hull material

Shipbuilding steel (standard)

Hull type

Single hull

Partly double bottom

Watertight bulkheads

4

Continuous decks

2

Main engine

1x Deutz SBV 6M 628- 4 stroke single acting 6 cylinder 240 x 280 mm diesel engine - 599 kW

Built: 1986

Manufacturer: Klöckner-Humboldt-Deutz AG

Propeller

1x Solid propeller - aft

Boiler

Water heater, oil fired
Year of manufacture: 1986

Electric Installations

1x 380/220 V - 260 kVA

1x 380 V - 120 kVA

1x 380 V - 50 kVA

Shaft generator

1x 120 kVA

Generators

1x Diesel generatorset 160 kVA

1x Diesel generatorset 100 kVA

Emergency generator

1x Diesel generatorset 50 kVA

Compressed air receivers

1x Receiver 500 litres - 30,0 bar

1x Receiver 250 litres - 30,0 bar

1x Receiver 50 litres - 10,0 bar

1x Receiver 40 litres - 10,0 bar

Bow thruster

1x Transverse thruster - 110 kW, forward

Tank capacities

MDO: 110 t
Gasoil: 11,5 t

Ballast: 906 t / 953 m³

Holds and hatches

1x Hold (steel floored)

1x Hatch 49,80 m x 8,20 m

Cargo capacity

Grain: abt. 95.000 ft³ / 2.688 m³

Anchor equipment

3x Anchors weight each 1.020 kg

Chain length: 357,50 m

Crew

11

Manager

Baltic Maritime Service Ltd.
3, C R Jakobsoni tn
Tallinn
Estonia

Owner

Pa Shipping Ltd.
60, Nevis Street
St. John's
Antigua and Barbuda

Special annotation

Wheelhouse hydraulic lowering
