| Westerschelde 00 May 2017 |
 |
 |
|
| Ant 08/06/2011 | Ant 08/06/11 | |
|
Name |
QAMUTIK |
|
Previous names |
08/1994 - 07/2008 Edisongracht 07/2008 - 11/2008 Qamutik 11/2008 - 06/2009 Edisongracht 06/2009 - 12/2009 Qamutik 12/2009 - 07/2010 Edisongracht |
|
Type |
Multi-purpose carrier - Container - Strengthened for heavy cargoes - Timber deck cargoes |
|
IMO-number |
9081289 |
|
Call sign |
CGCV |
|
Flag |
Canada |
|
Port of registry |
Montreal, QC |
|
Previous fags |
08/1994 - 07/2008 The Netherlands, Amsterdam - Call sign: PDUJ 07/2008 - 11/2008 Canada - Call sign: CGCV 11/2008 - 06/2009 The Netherlands, Amsterdam - Call sign: PDUJ 06/2009 - 12/2009 Canada - Call sign: CGCV 12/2009 - 2010 The Netherlands, Amsterdam - Call sign: PDUJ |
|
GT |
8.448 t |
|
DWT |
12.754 t |
|
NT |
4.651 t |
|
Number of 20ft containers |
Hold: 296 Deck: 434 Total: 730 |
|
Reefer capacity |
Hold: 136 Deck: 186 Total: 322 Power for reefer containers: 650 kW |
|
Length |
136,34 m overall 127,14 m between perpendiculars |
|
Breadth |
19,02 m moulded |
|
Draught |
Max: 8,51 m |
|
Depth |
11,65 m moulded |
|
Speed |
Ballast: 13,5 knots Max.: 16,0 knots |
|
Built |
1994 |
|
Keel laid |
24/09/1993 |
|
Launch date |
29/07//1994 |
|
Delivery date |
26/08/1994 |
|
Builder |
Frisian Shipbuilding Welgelegen B.V. Harlingen The Netherlands |
|
Yard number |
501 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Number of decks |
1 |
|
Main engine |
1x Wärtsilä Vasa 6R46 - 4 stroke single acting 6 cylinder 460 x 580 mm combustion engine 5.430 kW / 7.378 hp at 500 rpm |
|
Propeller |
1x Controllable pitch propeller |
|
Bow thruster |
1x 500 kW / 700 hp |
|
Number of holds |
2 |
|
Cargo hold capacity |
Hold 1: 208.000 ft³ / 5.890 m³ Hold 2: 557.250 ft³ / 15.780 m³ Total: 765.250 ft³ / 21.670 m³ |
|
Hold ventilation |
30x per hour /empty holds |
|
Hatches |
Weather deck: N° 1: 26,60 x 15,80 m N° 2: 31,74 x 15,80 m N° 3: 16,60 x 15,80m Tween deck: 91,94 x 15,80 m Consisting of 17 steel pontoons: 11x 6,35 x 15,80 m 2x 4,36 x 15,80 m 3x 3,19 x 15,80 m 1x 3,19 x 15,80 m |
|
Floor spaces |
Tank top: 1.280 m² Tween deck: 1.430 m² Weather deck: 1.280 / 1.500 m² |
|
Maximum load |
Weather deck hatch covers: 1,75 t/m² Tween deck hatch covers: 4,00 t/m² Tank top: 20,00 t/m² |
|
Tank capacities |
Fuel oil: 1.338 m³ Diesel oil: 173 m³ Ballast water 4.044 m³ |
|
Air changes |
30x per hour |
|
Lifting equipment |
Heavy lift derricks: 3x SWL 60 t at 16,00 m 3x SWL 40 t. at 24,00 m |
|
Crew size |
25 |
|
Manager |
Spliethoff's Bevrachtingskantoor B.V. Radarweg 36 1042 AA Amsterdam The Netherlands |
|
Previous manager |
08/1994 - 07/2008 Spliethoff's Bevrachtingskantoor B.V., Amsterdam - The Netherlands 07/2008 - 12/2009 Transport Nanuk Inc., Montreal - Canada |
|
Registered owner |
Transport Qamutik Inc. Bureau 2060, Edifice du Port de Montreal Montreal, QC H3C 3R5 Canada |
|
Previous owners |
08/1994 - 07/2008 C.V. Scheepvaartonderneming Edisongracht, Amsterdam - The Netherlands |
|
Latest data adjustment |
05 November 2022 |
