| Westerschelde 22 May 2018 |
 |
 |
 |
 |
 |
||||
| Westerschelde 22/05/18 | Westerschelde 22/05/18 | Antwerpen 31/12/19 | Antwerpen 31/12/19 | Westerschelde 24/04/16 | ||||
|
Name |
FEDERAL WESER |
|
Type |
Bulk carrier |
|
IMO-number |
9229972 |
|
Call sign |
V7WU4 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
Previous flags |
Cyprus, Limassol - Call sign: P3EJ9 |
|
GT |
22.654 t |
|
DWT |
Summer: 37.038,0 t Winter: 35.994,1 t |
|
NT |
12.073 t Panama: 18.880 t Suez: 22.643 t |
|
Length |
199,91 m overall 191,99 m between perpendiculars |
|
Breadth |
23,70 m registered |
|
Draught |
11,27 m |
|
Forecastle |
13,75 m |
|
Poop |
22,40 m |
|
Depth to main deck |
15,30 m moulded |
|
Speed |
13,5 knots |
|
Built |
2002 |
|
Keel laid |
22/12/2000 |
|
Launch date |
23/07/2001 |
|
Date of completion |
23/02/2002 |
|
Builder |
New Century Shipbuilding Co. Ltd - Jingjiang Shipyard Xingang Gangkou Jingjiang 214513, Jiangsu Province People's Republic of China |
|
Yard number |
JS00-018 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
9 |
|
Continuous decks |
2 |
|
Main engine |
1x MAN-B&W 6S46MC-C - 2 stroke single acting 6 cylinder 460 x 1.932 mm combustion engine 7.860 kW at 129 rpm Year of manufacture: 2001 Manufacturer: Hudong Heavy Machinery Co., Ltd. Foundry Branch 620 Donggou Donggao Road Pu Dong District 201208 Shanghai People's Republic of China |
|
Propeller |
1x Fixed pitch mono-block propeller - aft |
|
Boilers |
1x Steam boiler, oil fired - 9,0 bar Heating surface: 13,0 m² 1x Steam boiler, exhaust gas heated - 9,0 bar Heating surface: 179,0 m² Year of manufacture: 2001 Manufacturer: Shazhou Marine Boiler Factory Huan Chen Road,17 (South) Zhangjiagang 215600, Jiangsu People's Republic of China |
|
Electric installations |
1x Plant 440/220 V - 750 kVA 1x Plant 440/220 V - 750 kVA 1x Plant 440/220 V - 750 kVA 1x Plant 440 V - 173 kVA |
|
Diesel generators |
3x Yanmar 6N18AL-EV diesel engines each 660 kW at 900 rpm coupled with 3 generators each 600 kW, 450 Volt, 60 Hz |
|
Emergency generator |
1x Diesel generatorset 173 kVA |
|
Compressed air receivers |
2x Receivers each 4.000 litres - 30,0 bar 1x Receiver 250 litres - 30,0 bar 1x Receiver 60 litres - 30,0 bar 1x Receiver 500 litres - 7,0 bar |
|
Bow thruster |
1x Transverse thruster KAWASAKI - 900 kW, forward |
|
Number of holds |
6 Hold 1: 17,62 m x 21,50 m x 16,00 m Hold 2: 27,20 m x 21.50 m x 16,00 m Hold 3: 27,20 m x 21,50 m x 15,50 m Hold 4: 27,20 m x 21,50 m x 15,20 m Hold 5: 27,20 m x 21,50 m x 15,20 m Hold 6: 19,20 m x 21,50 m x 15,20 m |
|
Hold capacity |
Grain & bale Hold 1: 5.176 m³ Hold 2: 8.291 m³ Hold 3: 8.139 m³ Hold 4: 8.026 m³ Hold 5: 8.026 m³ Hold 6: 5.120 m³ Total: 42.778 m³ |
|
Number of hatches |
6 Hatch 1: 12,80 m x 15,60 m Hatch 2: 19,20 m x 17,60 m Hatch 3: 19,20 m x 17,60 m Hatch 4: 19,20 m x 17,60 m Hatch 5: 19,20 m x 17,60 m Hatch 6: 12,80 m x 17,60 m |
|
Hatch covers |
MacGregor hydraulic folding |
|
Tanktop strength |
20,0 t/m² |
|
Tank capacities |
Fuel oil: 1.329 m³ MDO: 436 m³ Fresh water: 356 m³ Ballast: 15.473,3 m³ |
|
Anchor equipment |
3x Anchors weight each 6.900 kg Chain length: 605,00 m Diameter: 64 mm |
|
Gear |
4x Centre-mounted hydraulic cranes Lifting capacity: SWL 40,0 t each Hoisting speed: 24,00 m/min Lifting height: 35,00 m |
|
Hold ventilation |
7x Air changes per hour for hold 1 6x Air changes per hour for all other holds |
|
Crew complement |
29 |
|
Manager |
Anglo-Eastern Ship Management Ltd. Hong Kong |
|
Commercial manager |
Fednav Ltd. Bureau 3500, 1000, rue de la Gauchetiere O Montreal QC H3B 4W5 Canada |
|
Registered owner |
Baffin Investments Limited c/o Fednav Ltd Bureau 3500, 1000, rue de la Gauchetiere O Montreal QC H3B 4W5 Canada |
|
Renamed |
06/2022 NJ Sunday Palau, Malakal Harbor - Call sign: T8A3924 Owner: NJ Sun Marine Ltd. Manager: NJ Trust Marine Ltd., Piraeus - Greece |
|
Latest data adjustment |
31 March 2023 |
