| Antwerpen 16 April 2013 |
|
Name |
CASSIOPEA |
|
Previous names |
1993 - 10.2005 Magellan Phoenix 2005 - 10.2008 Saronic Wave |
|
Type |
General cargo - Reefer |
|
IMO-number |
9047269 |
|
Call sign |
LYTA |
|
Flag |
Lithuania |
|
Port of registry |
Klaipeda |
|
GT |
7.326 t |
|
DWT |
8.043 t |
|
NT |
4.810 t |
|
Number of 20ft containers |
12 |
|
Number of 40ft containers |
6 |
|
Reefer plugs |
12 |
|
Length |
134,02 m overall 125,00 m between perpendiculars |
|
Breadth |
20,83 m extreme |
|
Draught |
7,57 m |
|
Depth |
10,17 m |
|
Speed |
18,0 knots |
|
Built |
1993 |
|
Keel laid |
03.12.1992 |
|
Date of completion |
28.09.1993 |
|
Builder |
Shin Kochi Jyuko K.K. Japan |
|
Yard number |
7031 |
|
Hull material |
Steel |
|
Main engine |
1x 8 UEC 45LA Builder: Kobe Diesel Co. Ltd. |
|
Propellers |
1 |
|
Generators |
3x Main generatorsets M200 Builder: Yanmar Co., Ltd. Amagasaki Plant |
|
Number of holds |
4 Hold 1: 62.642 ft³ / 728 m³ Hold 2: 103.336 ft³ / 1.185 m³ Hold 3: 114.607 / 1.346 m³ Hold 4: 113.545 ft³ / 1.278 m³ Total: 394.130 ft³ / 4.537 m³ |
|
Number of hatches |
4 Dimensions: 7,40 x 7,30 m |
|
Compartments |
15 |
|
Cooling sections |
8 |
|
Deck area |
4.536,82 m² |
|
Capable hold temperature |
+15/-25°C |
|
Tank capacities |
Fuel oil: 990,7 m³ Diesel oil: 173,2 m³ Fresh water: 256 m³ |
|
Ventilation/Air changes |
Vertical, 90/60 per hour |
|
Cargo gear |
8x Derricks - SWL 5,0 t |
|
Manager |
Limarko Shipping Company, AB |
|
Owner |
Limarko Shipping Company, AB |
|
Last update |
24.04.2013 |
