| Westerschelde 05 December 2011 |
|
Name |
BERIT |
|
Previous names |
1996 - 23.01.2004 RMS Aldebaran 23.01.2004 - 22.02.2006 HAV Aldebaran 22.02.2006 - 30.01.2007 Aldebaran |
|
Type |
General cargo ship - Equipped for carriage of containers |
|
IMO-number |
9156187 |
|
Call sign |
ZDHX2 |
|
Flag |
Gibraltar |
|
Port of registry |
Gibraltar |
|
GT |
1.864 t |
|
DWT |
2.518 t |
|
DWCC |
Summer: 2.350 t Winter: 2.250 t |
|
NT |
938 t |
|
Number of 20ft containers |
105 |
|
Length |
82,46 m overall 79,82 m registered |
|
Breadth |
11,35 m |
|
Draught |
4,798 m |
|
Forecastle |
6,62 m |
|
Poop |
15,60 m |
|
Air draft |
9,00 m ballast |
|
Depth |
6,10 m moulded |
|
Speed |
10,0 knots |
|
Built |
1996 |
|
Keel laid |
29.02.1996 |
|
Launch date |
17.10.1996 |
|
Date of completion |
12.1996 |
|
Builder |
Slovenske Lodenice a.s. |
|
Yard number |
1505 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Partly double bottom |
|
Watertight bulkheads |
4 |
|
Continuous decks |
2 |
|
Main engine |
1x Deutz SBV 8 M 628 - 4 stroke 8 cylinder 240x 280 mm diesel engine - 1.350 kW at 800 rpm Year of manufacture: 1996 Manufacturer: Motoren-Werke Mannheim AG |
|
Propeller |
1x Solid propeller - aft at 256 rpm |
|
Boilers |
1x Water heater, oil fired - 4,0 bar Year of manufacture: 1996 |
|
Electric installations |
2x Plant 380/ 220 V each 85 kVA 1x Plant 380 V - 85 kVA |
|
Generators |
2x Main diesel generatorsets each 85 kVA |
|
Emergency generator |
1x Diesel generatorset 85 kVA |
|
Compressed air receivers |
2x Receivers each 125 litres - 30,0 bar 1x Receiver 10 litres - 30,0 bar |
|
Bow thruster |
1x OMEGA jet 230 kW, forward |
|
Cargo capacity |
Grain & bales: 3.486 m³ - 123.000 ft³ |
|
Number of holds |
1 53,40 x 9,00 x 7,59 m |
|
Number of hatch |
1 53,40 x 9,00 m |
|
Hatch covers |
Kvaerner brug, folding type |
|
Strength |
Tanktop: 12,0 t/m² Hatch: 1,3 t/m² |
|
Ballast water |
1.059 m³ |
|
Anchor equipment |
3x Anchors weight each 1.290 kg Chain length: 385,00 m |
|
Manager |
Vaage Ship Management AS |
|
Operator |
Wagle Chartering AS |
|
Owner |
Vaagebulk II KS |
