| Westerschelde 02 February 2017 |
|
Name |
BLUE TUNE |
|
Type |
Multi-purpose dry cargo and container carrier - Carriage of dangerous goods - Refrigerated Cargo Boxed-shaped Singledecker |
|
IMO-number |
9491927 |
|
Call sign |
V2EU9 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John |
|
GT |
3.845 t |
|
DWT |
Summer: 5.201 t Winter: 5.036 t |
|
NT |
1.590 t |
|
Displacement |
7.029,62 t |
|
Length |
89,97 m overall 84,95 m between perpendiculars |
|
Breadth |
15,40 m moulded |
|
Draught |
Summer: 6,13 m Winter: 6,00 m |
|
Air draft |
22,30 m in ballast |
|
Freeboard |
1.480 mm |
|
Depth |
7,61 m moulded |
|
Speed |
11,8 knots |
|
Build |
2010 |
|
Keel laid |
08/12/2008 |
|
Launch date |
11/05/2010 |
|
Delivery date |
03/11/2010 |
|
Builder |
Israel Shipyards Ltd. Haifa Israel |
|
Yard number |
2027 |
|
Hull material |
Steel |
|
Hull type |
Double bottom |
|
Movable bulkheads |
2x Movable bulkheads (can be put as part tweendeck at after end of hold) |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 6L27/38 - 6 cylinder 270 x 380 mm combustion engine 2.040 kW at 800 rpm |
|
Propellers |
1x Controllable pitch propeller |
|
Generators |
2x Diesel generatorsets each 218 kW |
|
Number of holds |
1 |
|
Cargo hold capacity |
Grain & bale: 198.216 ft³ |
|
Number of hatches |
1 54,60 x12,60 m |
|
Hatch cover type |
Pontoon type hatch covers moved by 1 travelling gantry |
|
Max permitted loads |
Tanktop: 15,0 t/m² On deck: 1,75 t/m² |
|
Tank capacities |
Hydraulic oil: 0,80 m³ Lub oil: 12,20 m³ Fuel oil: 277,80 m³ Ballast: 2.075,90 m³ Fresh water: 49,40 m³ |
|
Crew |
10 |
|
Manager |
Pool Carriers Mbh & Co., KG Zirkusweg 1 20359 Hamburg Germany |
|
Registered owner |
Blue Tune Ltd. |
|
Latest data adjustment |
17 October 2024 |
