| Westerschelde 23 July 2017 |
 |
|
| Westerschelde 23/07/17 | |
|
Name |
MARIE LEHMANN |
|
Type |
General cargo carrier - Strengthened for heavy cargo |
|
IMO-number |
8707783 |
|
Call sign |
V2OA8 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John’s |
|
Previous flags |
1987 - 2004 Germany, Lubeck - Call sign: DKXL |
|
GT |
2.642 t |
|
DWT |
Summer: 3.017 t |
|
DWCC |
Summer: 3.320 t Winter: 3.220 t |
|
NT |
956 t |
|
Light ship |
1.367 t |
|
Number of 20ft containers |
198 |
|
Length |
87,99 m overall 89,06 m between perpendiculars |
|
Breadth |
12,80 m |
|
Draught |
5,18 m fully laden |
|
Air draft |
22,00 m in ballast 19,60 m loaded |
|
Depth |
7,45 m |
|
Speed |
11,0 knots |
|
Built |
1987 |
|
Keel laid |
29/05/1987 |
|
Launch date |
03/07/1987 |
|
Date of completion |
29/08/1987 |
|
Builder |
J.J. Sietas Kg Schiffswerft GmbH & Co. Neuenfelder Fährdeich 88 21129 Hamburg Germany |
|
Yard number |
1002 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull partly double bottom (e.g. interrupted in way of machinery space) |
|
Watertight bulkheads |
3 |
|
Movable bulkheads |
1x 3 position |
|
Main engine |
1x Wärtsilä 6R32 - 4 stroke 6 cylinder 320 x 350 mm combustion engine 1.835 kW / 2.495 hp at 750 rpm Builder: Wärtsilä Diesel OY, Vaasa - Finland |
|
Propellers |
1x Controllable pitch propeller |
|
Electric installations |
2x Plant 400/ 220 V - 120 kVA 1x Plant 400 V - 425 kVA 1x Plant 400 V - 25 kVA |
|
Shaft generator |
1x 425 kVA |
|
Generators |
2x Main diesel generatorsets each 120 kVA |
|
Emergency generator |
1x Diesel generatorset 25 kVA |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster Jastram - 165 kW |
|
Number of holds |
1x Box type 55,78 x 10,38 x 8,18 m |
|
Cargo hold capacity |
Grain: 4.870 m³ Bale: 4.842 m³ |
|
Number of hatches |
1 56,04 x10,40 m |
|
Hatch cover type |
Hydraulic folding |
|
Max permitted loads |
Tanktop: 12,0 t/m² Hatch covers: 1,75 t/m² |
|
Tank capacities |
Ballast: 1.659 t |
|
Anchor equipment |
3x Anchors weight each 1.590 kg Chain length: 412,50 m |
|
ISM & commercial manager |
Reederei Lehmann GmbH & Co. KG Lübeck Germany |
|
Previous owners |
Marie Lehmann c/o Reederei Lehmann GmbH & Co KG Lübeck Germany |
|
Renamed |
2017 Marie-B Antigua & Barbuda, St. John’s - Call sign: V2OA8 Manager: Jeb Bereederungsgesellschaft Mbh & Co.- Germany Registered owner: Marie B Schifffahrts GmbH & Co KG 10/2020 Rocket Racoon Antigua & Barbuda, St. John’s - Call sign: V2OA8 Owner: 1 Nauticore Schiffahrts UG - Germany Manager: Nauticore Shipmanagement UG - Germany 08/2023 Maureen S Antigua & Barbuda, St. John’s - Call sign: V2OA8 Owner & manager: Kevin S Gmbh & Co KG, Seevetal - Germany |
|
Latest data adjustment |
30 June 2024 |
