| Westerschelde 24 April 2017 |
 |
 |
 |
||
| Westerschelde 24/04/17 | Westerschelde 09/05/17 | Westerschelde 09/05/17 | ||
|
Name |
VON PERLE |
|
Previous names |
Rheinfels |
|
Type |
General cargo vessel - Equipped for carriage of containers |
|
IMO-number |
9014664 |
|
Call sign |
E5U3133 |
|
Flag |
Cook Islands |
|
Port of registry |
Avatiu |
|
Previous flags |
1991 - 2016 Antigua & Barbuda, St. John’s - Call sign: V2AI4 |
|
GT |
2.381 t |
|
DWT |
3.740 t |
|
NT |
1.369 t |
|
Displacement |
4.851 t |
|
Light weight |
1.151,33 t |
|
Number of 20ft containers |
In hold: 108 On deck: 68 Total: 176 |
|
Length |
88,77 m overall 81,85 m between perpendiculars |
|
Breadth |
12,80 m extreme |
|
Draught |
Max: 5,47 m |
|
Keel to mast end |
24,50 m |
|
Freeboard |
1.760 mm |
|
Depth |
7,10 m moulded |
|
Speed |
11,7 knots |
|
Built |
1991 |
|
Keel laid |
07/11/1990 |
|
Launch date |
27/06/1991 |
|
Date of completion |
01/12/1991 |
|
Builder |
Slovenske Lodenice A.S. Komarno Slovakia |
|
Yard number |
2901 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
4 |
|
Movable bulkheads |
2x Moveable bulkheads, full hold height, 10 positions |
|
Continuous decks |
1 |
|
Main engine |
1x Duetz SBV8M628 - 4 stroke 8 cylinder 240 x 280 mm combustion engine 1.500 kW / 2.039 hp at 900 rpm Build: 1991 Builder: Deutz MNM Motoren Werke Mannheim AG - Germany |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired |
|
Generators |
3x MAN D 2866 E main diesel generatorsets each 130 kVA |
|
Emergency generator |
1x Deutz KHD F6L912 diesel generatorset |
|
Bow thruster |
1x Jastram BU40 - 185 kW |
|
Number of holds |
1x Box type 56,50 x 10,20 x 8,15 m |
|
Cargo hold capacity |
Bale & grain: 4.591 m³ |
|
Number of hatches |
1 56,50 x 10,20 m |
|
Hatches type |
Kvaerner multifold crocodile |
|
Max permitted loads |
On deck/hatch covers: 1,56 t/m² |
|
Tank capacities |
Water ballast: 1.677,31 m³ Fuel main engine: 166 m³ Fuel auxiliary engines: 33 m³ |
|
Crew |
9 |
|
Manager |
Wessels Reederei GmbH & Co., KG Haren Ems Germany |
|
Previous managers |
1991 - 1992 Wessels Befrachtungs- und Bereederungs GmbH & Co. KG 1992 - 1998 River-Liner Holding GmbH & Co. KG 1998 - 2006 Wessels Befrachtungs- und Bereederungs GmbH & Co. KG |
|
Registered owner |
Wessels Reederei Haren Ems Germany |
|
Renamed |
2020 Janine Republic of Panama, Panama City - Call sign: H9NR Owner: Nismar Shipping Ltd. - Turkey Manager: Von See Shipping Ltd. - Cook Islands |
|
Latest data adjustment |
26 September 2022 |
