| Westerschelde 10 May 2020 |
 |
 |
|
| Westerschelde 10/05/20 | Westerschelde 10/05/20 |
|
Name |
CHINA PRIDE |
|
Type |
Bulk carrier |
|
IMO-number |
9558799 |
|
Call sign |
VRFO9 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
91.373 t Suez: 92.610,3 t |
|
DWT |
Summer: 177.856 t |
|
NT |
58.745 t Suez: 86.728,98 t |
|
Displacement |
202.712 t |
|
Length |
292,00 m overall 282,00 m between perpendiculars |
|
Breadth |
45,00 m moulded |
|
Draught |
Summer: 18,30 m |
|
Keel to mast end |
58,80 m |
|
Freeboard |
6.535 mm |
|
Depth |
24,80 m moulded |
|
Speed |
15,0 knots |
|
Built |
2009 |
|
Keel laid |
15/05/2006 |
|
Launch date |
21/05/2009 |
|
Delivery date |
07/08/2009 |
|
Builder |
Shanghai Waigaoqiao Shipbuilding Co., Ltd. 3001 Zhouhai Road Pudong New Area, Shanghai, 200137 China |
|
Yard number |
H1156 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Main engine |
1x MAN-B&W 6S70MC - 2 stroke 6 cylinder 700 x 2.674 mm combustion engine Mcr 16.860 kW at 91,0 rpm Manufacturer: CSSC-MES Diesel Co., Ltd. |
|
Propellers |
1x Fixed pitch propeller Manufacturer: Dalian Marine Propeller Plant |
|
Boilers |
Exhaust gas and fired boiler Mission TM OC - 9,0 MPa Manufacturer: Aalborg Industries Ltd. |
|
Generators |
3x Main diesel generatorsets each 900 kW Manufacturer: Wuxi Fenxi Electrical Machine Co., Ltd. |
|
Number of holds |
9 |
|
Cargo hold capacity |
Grain: 194.179,1 m³ Bale: 183.425 m³ |
|
Number of hatches |
9 |
|
Tank capacities |
Fuel oil: 4.776,10 m³ Ballast: 141.786,90 m³ Diesel oil: 383,31 m³ Lub oil: 300,58 m³ Fresh water: 568,30 m³ |
|
Lifting equipment |
1x Engine room overhead crane - SWL 5,0 t Manufacturer: Jiangyin Chenjiang Ship Equipment Co.,Ltd. 1x Provision handling crane port - SWL 5,0 t 1x Provision handling crane starboard - SWL 5,0 t Manufacturer: zhengjinang Marine Auxiliary Machine Works |
|
Cargo gear |
Gearless |
|
Crew size |
30 |
|
ISM & commercial manager |
Chinese Maritime Transport Ltd. 9th Floor, Chinese Maritime Building, 15, Jinan Road, Section 1, Zhongzheng District, Taipei City, 10051, China, Republic of (Taiwan) |
|
Registered owner |
China Pride Shipping Ltd. Care of Chinese Maritime Transport Ltd , 9th Floor, Chinese Maritime Building, 15, Jinan Road, Section 1, Zhongzheng District, Taipei City, 10051, China, Republic of (Taiwan) |
|
Latest data adjustment |
09 February 2022 |
