Malaga, Spain 23 August 2021 |
|
Name |
OSLO FOREST 1 |
|
Previous names |
06/2011 - 10/2017 Marvel Scan |
|
Type |
General dry cargo vessel - Container carriage |
|
IMO-number |
9534444 |
|
Call sign |
LALQ8 |
|
Flag |
Norway |
|
Port of registry |
Oslo |
|
Previous flags |
2011 - 2017 The Netherlands, Groningen - Call sign: PBSQ 2017 - 2020 Republic of Singapore, Singapore City - Call sign 9V5499 |
|
GT |
6.693 t |
|
DWT |
Summer: 10.001,5 t |
|
NT |
3.441 t Panama: 5.845 t Suez: 5.944,27 t |
|
Number of 20ft containers |
On deck: 172 In hold: 232 Total: 404 |
|
Length |
116,26 m overall 112,76 m between perpendiculars |
|
Breadth |
17,80 m |
|
Draught |
Summer: 7,80 m |
|
Depth |
10,50 m moulded |
|
Speed |
14,0 knots |
|
Built |
2011 |
|
Keel laid |
15/12/2008 |
|
Launch date |
11/03/2011 |
|
Date of completion |
06/05/2011 |
|
Builder |
Scheepswerf Peters B.V. Kampen The Netherlands |
|
Yard number |
902 |
|
Hull material |
Steel |
|
Movable bulkheads |
3x Grain movable bulkheads - 6 positions |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 8M32 - 4 stroke single acting 8 cylinder 320 x 480 mm combustion engine 4.000 kW / 5.438 bhp at 600 rpm Manufacturer: Caterpillar Motoren GmbH & Co.; K.G., Kiel - Germany |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired Manufacturer: Viessmann Werke GmbH & Co. |
|
Shaft generator |
1x Stamford HCM634G generators 504 ekW |
|
Generators |
3x Scania CV D11264M main diesel generatorsets each 377 kW at 1.500 rpm |
|
Bow thruster |
1x Wärtsilä 450 kW |
|
Number of holds |
1 70,48 x 12,20 narrowing to 12,64 m Height of cargo holds: 11,79 m |
|
Cargo hold capacity |
Grain: 12.425,9 m³ Bale: 11.581 m³ |
|
Number of hatches |
1 70,51 x 17,3 m |
|
Hatch cover type |
Pontoon |
|
Max permitted loads |
Tanktop: 18,0 t/m² Tweendeck pontoons: 3,5 t/m² Weatherdeck hatch: 2,6 t/m² |
|
Tank capacities |
IFO: 568 m³ GO: 69,4 m³ Fresh water: 95,8 m³ Ballast: 3.991,8 m³ |
|
Cargo gear |
2x NMF cranes - SWL 80,0 t each |
|
ISM & Commercial manager |
Bulkship Management A.S. 6th Floor, Ruselokkveien 0251 Oslo Norway |
|
Previous managers |
06/2011 - 10/2017 CFL Shipmanagement B.V., Groningen - The Netherlands |
|
Registered owner |
Drimquest Ltd. - 17, Georgiou Karaiskaki Street, 3032 Limassol - Cyprus Care of Bulkship Management AS 6th Floor, Ruselokkveien 6 0251 Oslo Norway |
|
Previous names & owners |
06/2011 - 10/2017 Marvel Scan - CFL Shipmanagement B.V., Groningen - The Netherlands 10/2017 - 12/2020 Olso Forest 1 - Oslo Forest Pte Ltd., Oslo - Norway |
|
Latest data adjustment |
23 September 2021 |
