Westerschelde 08 May 2020 |
 |
 |
 |
 |
|||
| Westerschelde 25/05/19 | WS 25/05/19 | Westerschelde 23/09/20 | Westerschelde 23/09/20 |
|
Name |
ROYAL KLIPPER |
|
Previous names |
Build as: 2000 Equator Stream |
|
Type |
Refrigerated cargo ship - Container ship |
|
IMO-number |
9172959 |
|
Call sign |
D5VQ5 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
01/2000 - 12/2019 The Netherlands, Scheveningen - Call sign: PCIH |
|
GT |
11.382 t |
|
DWT |
Summer: 12.906 t |
|
NT |
6.408 t Panama: 10.045 t Suez: 10.107,81 t |
|
Number of 20ft containers |
390 |
|
Reefer hold capacity |
132 |
|
Reefer plug |
185 |
|
Length |
155,00 m overall 145,09 m between perpendiculars |
|
Breadth |
24,02 m extreme |
|
Draught |
Summer: 10,11 m |
|
Freeboard |
3.712 mm |
|
Depth |
13,81 m to main deck |
|
Speed |
Max: 22,5 knots |
|
Built |
2000 |
|
Keel laid |
09/1999 |
|
Delivery date |
04/02/2000 |
|
Builder |
Kitanihon Shipbuilding Co., Ltd. Hachinohe Japan |
|
Yard number |
320 |
|
Hull material |
Steel |
|
Watertight compartments |
7 |
|
Continuous decks |
4 |
|
Main engine |
1x Hitachi/B&W 8S50MC-C - 2 stroke single acting 8 cylinder 500 x 2.000 mm combustion engine 12.621 kW / 17.148 hp at 127,0 rpm Manufacturer: Hitachi Shipbuilding & Engineering Company Ltd. (Hitachi Zosen K.K.), Ariake - Japan |
|
Propellers |
1 Controllable pitch propeller - aft at 127,0 rpm |
|
Boilers |
1x CHO MIURA 18,00 m² - 10,0 bar 1x CHR MIURA 122,00 m² - 5,0 bar |
|
Generators |
4x Yanmar Diesel 6N260N-EN main diesel generatorsets each 1.500 kVA - 1.200 kW - 1.799 hp |
|
Emergency generator |
1x Diesel generatorset 90 kVA - 72 kW - 144 hp |
|
Bow thruster |
1x 650 kW |
|
Number of holds |
4 |
|
Number of compartments |
19 |
|
Cargo hold capacity |
15.917 m³ |
|
Temperature zones |
8 |
|
Number of hatches |
4 Hatch 1: 8,00 x 10,60 m Hatches 2-4: 13,50 x 10,60 m |
|
Pallets |
8.010 |
|
Number of decks |
4 |
|
Minimum deck height |
2,30 m |
|
Air circulations |
90x p/hr |
|
Air renewals |
4x p/hr |
|
Tank capacities |
Fuel oil: 1.982,51 m³ Diesel oil: 167 m³ |
|
Cargo gear |
4 2x Crane - SWL 40,0 t each 2x Crane - SWL 12,0 t each |
|
ISM & commercial manager |
Seatrade Groningen B.V. Leonard Springerlaan 17 9727 KB Groningen The Netherlands |
|
Previous managers |
01/2000 - 05/2006 Jaczon Rederij & Haringhandel B.V., Scheveningen - The Netherlands 05/2006 -09/2021 Seatrade Groningen B.V., Groningen - The Netherlands |
|
Registered owner |
Balmoral Partners Ltd., Monrovia - Liberia Care of Seatrade Groningen BV Leonard Springerlaan 17 9727 KB Groningen The Netherlands |
|
Previous owners |
01/2000 - 12/2019 Jaczon Royal Klipper B.V., Flushing - The Netherlands |
|
Sister ships |
Comoros Stream |
|
Renamed |
09/2021 Ceres Three Bahamas, Nassau - Call sign: C6FE4 Manager: Wallem Shipmanagement Ltd., Hong Kong - China Owner: Project Ceres Three Ltd, Nassau - Bahamas |
|
Latest data adjustment |
10 August 2022 |
