Westerschelde 06 July 2019 |
 |
| Westerschelde 06/07/19 |
|
Name |
ATLANTIC WINTER |
|
Previous names |
2011 Launch as: Beluga Prediction 2011 - 04/20102 Atlantic Winter 04/2011 - 04/2014 BBC Winter 04/2014 - 2015 Thorco Winter |
|
Type |
Heavy lift multi-purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo |
|
IMO-number |
9467146 |
|
Call sign |
CQDI |
|
Flag |
Portugal |
|
Port of registry |
Madeira |
|
Previous flags |
2011 - 2015 Liberia, Monrovia - Call sign A8XF7 |
|
GT |
15.549 t |
|
DWT |
Summer: 19.306,6 t |
|
NT |
6.089 t |
|
Number of 20ft containers |
On deck: 504 in hold: 507 Total: 1.011 |
|
Container capacity 14t |
779 |
|
Reefer capacity |
96 FEU + 28 TEU |
|
Length |
166,14 m overall 156,00 m between perpendiculars |
|
Breadth |
23,27 m extreme 22,91 m moulded |
|
Draught |
Summer: 9,80 m |
|
Air draft |
45,62 m |
|
Depth |
13,90 m |
|
Speed |
Max: 18,0 knots |
|
Built |
2011 |
|
Keel laid |
08/07/2010 |
|
Launch date |
28/12/2010 |
|
Date of completion |
02/11/2011 |
|
Builder |
China Changjiang Shipping Group Qingshan Shipyard Wuhan China |
|
Yard number |
QS20060324 |
|
Hull material |
Steel |
|
Main engine |
1x MAN-W&W 7L58/64 CD - 4 stroke 7 cylinder combustion engine 9.800 kW |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
Auxiliary boiler, composite MISSION TM OC |
|
Shaft generator |
1.500 kW |
|
Generators |
3x Caterpillar 3412 DITA main diesel generatorsets each 500 kW |
|
Emergency generator |
1x Diesel generatorset 99 KW |
|
Bow thruster |
1x 800 kW |
|
Number of holds |
2 |
|
Cargo hold capacity |
23.600 m³ |
|
Number of hatches |
2 |
|
Space |
Hatchcover: abt. 1.937 m² Tweendeck: 1.811 m² + 6 extra panels Lower hold: 1.786 m² Total: 5.534 m² + 6 extra panels |
|
Tank capacities |
Ballast: 9.657,5 m³ |
|
Anchor equipment |
Length: 577,90 m Diameter: 60 mm |
|
Cargo gear |
2x NMF cranes - SWL 400 t each 1x NMF crane - SWL 120 t |
|
Manager |
Heino Winter Gmbh & Co KG Hein-Sass-Weg 27, 21129 Hamburg, Germany |
|
Renamed |
2020 Lisa Portugal, Madeira - Call sign CQDI Owner: SAL Shipping UG (haftungsbeschränkt) & Co. KG ACM MS "LISA" Manager: Reedereiverwaltung Heino Winter GmbH & Co. KG |
|
Latest data adjustment |
01 March 2021 |
