Westerschelde 27 September 2018 |
 |
 |
|
| Vlissingen 26/09/18 | Vlissingen 26/09/18 |
|
Name |
TAI SUMMIT |
|
Type |
Bulk carrier - Carriage of dangerous goods - Handymax |
|
IMO-number |
9727144 |
|
Call sign |
3FZX4 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
34.009 t Suez: 34.968,1 t |
|
DWT |
Summer: 60.618 t |
|
NT |
19.892 t Suez: 31.916,75 t Panama: 28.178,31 t |
|
Displacement |
70.903 t |
|
Length |
199,98 m overall 196,00 m between perpendiculars |
|
Breadth |
32,26 m moulded |
|
Draught |
Summer: 12,85 m |
|
Freeboard |
5.536 mm |
|
Speed |
Max: 14,3 knots |
|
Built |
2016 |
|
Keel laid |
15/09/2015 |
|
Launch date |
18//12/2013 |
|
Delivery date |
18/04/2016 |
|
Builder |
Oshima Shipbuilding Co., Ltd. 1605-1 Oshima-Cho Saikai City, 857-2494 Japan |
|
Yard number |
10771 |
|
Hull material |
Steel |
|
Hull type |
Double bottom |
|
Main engine |
1x Mitsui/MAN-B&W 6S50ME-B9.3 - 6 cylinder 500 x 2.214 mm combustion engine 7.260 kW at 99,0 rpm Manufacturer: Mitsui Engr. & Shipbuilding Co., Ltd. |
|
Propellers |
1x Fixed pitch solid keyless propeller - 4 blades Manufacturer: Nakashima Propeller Co., Ltd. |
|
Boilers |
1x Auxiliary boiler - 6,9 Mpa Manufacturer: Osaka Boiler Mfg. Co., Ltd. |
|
Generators |
3x Main diesel generatorsets each 570 kW Manufacturer: Taiyo Electric Co., Ltd. |
|
Number of holds |
5 |
|
Cargo hold capacity |
Grain: 76.578 m³ Bale: 75.096 m³ |
|
Number of hatches |
5 |
|
Tank capacities |
Fuel oil: 2.042 m³ Ballast: 33.688 m³ Fresh water: 369 m³ Diesel oil: 21 m³ Lube oil: 97,6 m³ |
|
Cargo gear |
4x Deck cranes - SWL 30,0 t each Manufacturer: Iknow Machinery Co., Ltd. |
|
Crew |
23 |
|
Registered owner |
Tai Shing Maritime Co., SA c/o Taiwan Navigation Co Ltd, 29, Jinan Road, Section 2, Zhongzheng District, Taipei City, 10054, China Republic of Taiwan |
|
Latest data adjustment |
11 September 2020 |
