Weserborg 01

Antwerpen 06 February 2020



Name

WESERBORG

Previous names

01/2011 - 01/2014 Baltic Island

01/2014 - 01/2019 NBP Island

Type

Multi-purpose dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo

IMO-number

9505558

Call sign

PCIZ

Flag

The Netherlands

Port of registry

Delfzijl

Previous flags

2011 - 2019 Antigua & Barbuda, St. John's - Call sign: V2FH3

GT

6.668 t

DWT

Summer: 9.278 t

NT

3.625 t

Number of 20ft containers

132

Length

106,99 m overall

103,29 m registered

Breadth

18,42 m moulded

Draught

Max: 8,00 m

Air draft

31,60 m in ballast

Depth

10,50 m moulded

Speed

13,0 knots

Built

2011

Keel laid

30/12/2008

Launch date

11/06/2010

Date of completion

05/01/2011

Builder

Nanjing Huatai Shipyard Co., Ltd.

Dui Nan Wharf, Ba Gua Zhou

Nanjing, Jiangsu

People's Republic of China

Yard number

HT07-4-02

Hull material

Shipbuilding steel (standard)

Higher tensile steel

Hull type

Partly double bottom (e.g. interrupted in way of machinery space)

Watertight bulkheads

5

Continuous decks

1

Main engine

1x MaK 8M32C - 4 stroke 8 cylinder 320 x 480 mm combustion engine 3.840 kW at 600 rpm

Year of manufacture: 2009

Manufacturer: Caterpillar Motoren GmbH & Co. KG

Falckensteiner Str. 2

24159 Kiel

Federal Republic of Germany

Propellers

1x Controllable pitch propeller - aft at 148 rpm

Boilers

1x Thermal oil heater, exhaust gas heated - 10,0 bar

Heating surface: 52,6 m²

Year of manufacture: 2009

Manufacturer: Alfa Laval Aalborg B.V.

Ohmweg 8

3208 KE Spijkenisse

The Netherlands

1x Thermal oil heater, oil fired - 13,0 bar

Heating surface: 016,0 m²

Year of manufacture: 2009

Manufacturer: Alfa Laval Aalborg A/S Division Boiler Production

Gasvaerksvej 24

9100 Aalborg

Kingdom of Denmark

Electric installations

2x Plants each 400 V - 475 kVA

1x Plant 400 V - 625 kVA

1x Plant 400 V - 100 kVA

1x Plant 24 V - 135 Ah

2x Plants each 24 V - 176 Ah

1x Plant 24 V - 200 Ah

1x Plant 24 V - 280 Ah

1x Plant 24 V - 360 Ah

Shaft generator

1x 625 kVA

Generators

2x Main diesel generatorsets each 475 kVA

Emergency generator

1x Diesel generatorset 100 kVA

Batteries

1x Battery for automation 280 Ah

1x Battery for UPS navigation 200 Ah

1x Battery for start auxiliary engine 180 Ah

1x Battery for start auxiliary engine 180 Ah

2x Batteries for start emergency engine each 176 Ah

1x Battery for UPS radio 135 Ah

Compressed air receivers

2x Receivers each 400 litres - 33,0 bar

1x Receiver 250 litres - 11,0 bar

1x Receiver 30 litres - 11,0 bar

Bow thruster

1x Transverse thruster 450 kW, forward

Number of holds

3

Hold 1: 16,10 x 15,20 x 13,20 m

Hold 2: 25,90 x 15,20 x 11,60 m

Hold 3: 25,90 x 15,20 x 11,60 m

Cargo hold capacity

Grain/bale: 427.944 ft

Hold ventilation

Hold 1: 2 fans, cap. abt. 15.000 m³/h, air changes abt. 10,21 times/h

Hold 2: 2 fans, cap. abt. 25.000 m³/h, air changes abt. 10,94 times/h

Hold 3: 2 fans, cap. abt. 25.000 m³/h, air changes abt. 10,94 times/h

Number of hatches

3

Hatch 1: 17,10 x 16,20 m

Hatch 2: 27,90 x 16,20 m

Hatch 3: 27,90 x 16,20 m

Anchor equipment

3x Anchors weight each 3.540 kg

Chain length: 522,50 m

Crew size

13

Manager

Wagenborg Shipping B.V.

Marktstraat 10

9934 CK Delfzijl

The Netherlands

Previous managers

01/2011 -08/2012 - W. Bockstiegel Reederei GmbH & Co. KG, Emden - Germany

Registered owner

Borg Island B.V.

Delfzijl

The Netherlands

Previous owners

01/2011 -01/2014 Baltic Island - Baltic Island G.m.b.H. & Co. K.G., Emden - Germany

01/2014 - 11/2016 NBP Island - NBP Island UG

Latest data adjustment

10 May 2020
