Name |
NORGAS ORINDA |
|
Type |
Liquefied gas tanker |
|
IMO-number |
9240122 |
|
Call sign |
9V8456 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
Previous flags |
2002 - 2011 Hong Kong |
|
GT |
8.720 t |
|
DWT |
Summer: 9.352 t |
|
NT |
2.617 t |
|
Length |
124,90 m overall 115,00 m between perpendiculars |
|
Breadth |
19,80 m extreme |
|
Draught |
8,30 m |
|
Keel to mast end |
37,60 m |
|
Depth |
11,50 m |
|
Speed |
16,0 knots |
|
Built |
2002 |
|
Keel laid |
10/06/2001 |
|
Launch date |
21/09/2001 |
|
Date of completion |
10/10/2002 |
|
Builder |
Hudong Zhonghua Shipbuilding Group Co., Ltd. Shanghai China |
|
Yard number |
429 |
|
Hull material |
Steel |
|
Hull type |
Double side |
|
Main engine |
1x MAN-B&W 6L48/60 - 4 stroke 6 cylinder 480 x 600 mm combustion engine 6.300 kW / 8.565 hp at 500 rpm Builder: MAN B&W Diesel AG, Augsburg - Germany |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x Thermal oil heater, exhaust heated 1x Thermal oil heater, oil fired |
|
Generators |
4x MAN 2842LE 301 diesel generatorsets |
|
Emergency generator |
1x MAN D2866E diesel generatorset |
|
Bow thruster |
1x 700 kW |
|
Number of tanks |
3 |
|
Cargo tank capacity |
8.461 m³ |
|
Max. pressure |
7,0 bar |
|
Min. tank temp |
-104°C |
|
Number of pumps |
1x Cargo pump 640 m³/h 1x Cargo pump 380 m³/h |
|
Tank capacities |
Ballast: 4.961 m³ |
|
Anchor equipment |
Length: 275,00 m Diameter: 50 mm |
|
Manager |
Bernhard Schulte Shipmanagement (Hellas) SP LLC 6-8 Kifissias Ave Maroussi, 15125 Greece |
|
Previous managers |
I.M.skaugen Marine Services Pte. Ltd.,Singapore - Republic of Singapore Norgas Carriers Pte. Ltd. |
|
Operator |
Norgas Carriers Private Limited 78 Shenton Way #17-03 Singapore 079120 Republic of Singapore |
|
Registered owner |
Orinda Shipping Company Pte. Ltd. |
|
Previous owners |
2002 - 2006 Norgas Carriers AS 2006 - 2011 Somargas Ltd. 2011 - 2013 Somargas II Pte. Ltd. |
|
Renamed |
06/2019 Coral Orinda Republic of Singapore, Singapore City - Call sign: 9V8456 Owner: Orinda Shipping Company Pte. Ltd. Manager: Anthony Veder Chartering BV |
|
Latest data adjustment |
04 March 2022 |
