Vlissingen 13 August 2015 |
 |
|
| Vlissingen 18/07/15 | |
|
Name |
OSTSEE |
|
Type |
Trailing suction hopper dredger |
|
IMO-number |
9105152 |
|
Call sign |
5BAK4 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
Previous flags |
The Netherlands, Rotterdam - Call sign: PBMY4 |
|
GT |
3.785 t |
|
DWT |
Summer: 4.745 t |
|
NT |
1.135 t |
|
Light ship |
2.307 t |
|
Length |
99,83 m overall 90,25 m between perpendiculars |
|
Breadth |
17,75 m overall |
|
Draught |
5,51 m |
|
Keel to mast end |
32,50 m |
|
Freeboard |
1.260 mm |
|
Depth |
6,20 m moulded |
|
Speed |
Max: 14,0 knots |
|
Built |
1995 Refit: 2014 Peene-Werft GmbH, Wolgast - Germany - Yard number: 175 |
|
Date of completion |
30/06/1995 |
|
Builder |
Detlef Hegemann Rolandwerft GmbH & Co. Berne Germany |
|
Yard number |
429 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
2x MAN 6L32/40 - 4 stroke 6 cylinder 320 x 400 mm combustion engines each 2.640 kW Total 5.280 kW / 7.178 hp at 750 rpm Built: 1994 |
|
Propellers |
2x Controllable pitch propellers - aft at 220 rpm |
|
Shaft generator |
2x 3.000 kVA - 2.400 kW |
|
Generators |
2x Deutz MWM TBD 616 V8 diesel generatorsets each 380 kVA - 304 kW - 469 hp |
|
Emergency generator |
1x Deutz MWM BF 6L 513 RC diesel generatorset 138 kVA - 110 kW - 163 hp |
|
Bow thruster |
1x 400 kW |
|
Propulsion power |
Free sailing: 5.280 kW Dredging: 2.550 kW |
|
Total installed power |
6.090 kW |
|
Hopper volume |
3.400 m³ |
|
Dredging depth |
25,0 m |
|
Suction pipe diameter |
2x 700 mm |
|
Number of dredging pipes |
2 |
|
Shore delivery pipe |
750 mm |
|
Installed dredge pump power |
|
|
Dredging functions |
|
|
Tank capacities |
Marine gas oil: 702,5 m³ Fresh water: 47,9 m³ Lub oil: 45,000 litres |
|
Anchoring system |
3x Anchors - 2x bow / 1x stern |
|
Accommodation |
13 Men |
|
Owner |
MMC - Dutch Marine Contractors |
|
Renamed |
2017 Optimus Russia, Arkhangelsk - Call sign: UBUO9 Manager: MRTS West LLC Owner: MRTS Holding LLC |
|
Latest data adjustment |
08 September 2023 |
