Westerschelde 21 March 2019 |
 |
| WS 21/03/19 |
|
Name |
JB-119 |
|
Previous names |
2004 - 2015 Odin |
|
Type |
Self elevating platform vessel - Jack-up platform |
|
IMO-number |
8768062 |
|
Call sign |
C6BF6 |
|
Flag |
Bahamas |
|
Port of registry |
Nassau |
|
Previous flags |
2004 - 2015 Germany - Call sign: DAYQ |
|
GT |
2.636 t |
|
DWT |
Summer: 1.016 t |
|
NT |
791 t |
|
Length |
50,45 m overall 46,78 m between perpendiculars |
|
Breadth |
30,86 m extreme 30,00 m moulded |
|
Draught |
Max: 3,25 m |
|
Depth |
4,60 m |
|
Built |
2004 |
|
Keel laid |
11/05/2004 |
|
Launch date |
07/10/2004 |
|
Date of completion |
24/11/2004 |
|
Builder |
Western Shiprepair Yard Klaipeda Lithuania |
|
Yard number |
018 |
|
Hull material |
Steel |
|
Deck area |
700 m² |
|
Legs |
Length: 60,00 m Diameter: 2,00 x 2,00 m |
|
Spudcan surface |
10,50 m² each (removable) |
|
Jacking system |
Make: Muns Techniek Jacking speed up: 1,25 m/minute Jacking speed down: 1,25 m/minute Max. pay load: 900 t |
|
Mooring system |
Winches: 2x 17,5 t double drum winches 2x 17;5 t single drum winches Anchors:4x Delta Flipper - 4,0 t |
|
Moon pools |
2x Diameter 550 mm |
|
Jacking conditions |
Wave height / period max: 1,20 meter/4,3 seconds Wind speed max.: 12,00 m/second (current max. 0,5 m/s) |
|
Tank capacities |
Ballast: 1.490,8 m³ |
|
Main crane |
Make: Liebherr Type: BOS 7500 heavy lift crane Capacity: 300 t at 15,00 meter radius 82 t at 40,00 meter radius Boom length: 66,00 - 78,00 m |
|
Accommodation |
Up to 40 persons |
|
Manager |
Jack-Up Barge Operations B.V. Krausstraat 14-16 3364 AD Sliedrecht The Netherlands |
|
Registered owner |
Jack-Up Barge Operations B.V. Krausstraat 14-16 3364 AD Sliedrecht The Netherlands |
|
Latest data adjustment |
21 October 2021 |
