Westerschelde 11 January 2020 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 11/01/20 | Westerschelde 11/01/20 | Westerschelde 21/03/20 | Westerschelde 05/05/17 | Westerschelde 05/05/17 | Westerschelde 05/05/17 |
|
Name |
S SANTIAGO |
|
Previous names |
2006 - 08/2011 MSC Benedetta 08/2011 - 02/2015 SCT Santiago 02/2015 - 12/2016 S Santiago 12/2016 - 02/2017 ANL Wantirna |
|
Type |
Gearless cellular container carrier - Carriage of dangerous goods |
|
IMO-number |
9302566 |
|
Call sign |
V7NF7 |
|
Flag |
Marshall Island |
|
Port of registry |
Majuro |
|
GT |
54.214 t registered |
|
DWT |
Summer: 68.125,9 t |
|
NT |
31.226 t registered |
|
Number of 20ft containers |
On deck: 2.778 In hold: 2.282 Total: 5.060 |
|
Container capacity 14t |
3.425 |
|
Reefer capacity |
On deck: 454 |
|
Length |
294,10 m overall 283,75 m between perpendiculars |
|
Breadth |
30,20 m moulded |
|
Draught |
13,52 m |
|
Reg. dimensions L x B x D |
283,11 x 32,20 x 18,93 m |
|
Rule dimensions L x B x D |
278,43 x 32,20 x 21,60 m |
|
Keel to mast end |
55,90 m |
|
Freeboard |
3.939 mm |
|
Depth |
18,93 m |
|
Speed |
24,3 knots |
|
Built |
2006 |
|
Keel laid |
22/02/2006 |
|
Launch date |
12/04/2006 |
|
Date of completion |
29/05/2006 |
|
Builder |
Hanjin Heavy Industries & Construction Co., Ltd. Pusan South Korea |
|
Yard number |
N145 |
|
Hull material |
Steel |
|
Watertight bulkheads |
10 |
|
Main engine |
1x MAN-B&W/Hyundai 9K9080MC-C Mk6 - 2 stroke 9 cylinder 900 x 2.300 mm combustion engine 41.130 kW / 55.920 bhp at 104,0 rpm Build: 02/2006 Manufacturer: Hyundai Heavy Industries Co., Ltd., Ulsan - South Korea |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary boiler CPB - 8,8 bar Build: 02/2006 Manufacturer: Kangrim Heavy Industrial Co., Ltd., Changwon - South Korea |
|
Generators |
4x Hyundai/HimSen 8H25/33 main diesel generatorsets each 1.680 kW - 2.237 kVA 450 Volt |
|
Bow thruster |
1x 1.900 kW |
|
Number of tanks |
Ballast: 25 Fuel oil: 14 Lubricating oil: 6 Diesel oil: 3 Sludge: 1 Chain: 1 Slop: 1 |
|
Tank capacities |
Fuel oil: 8.120, 8 m³ Fresh water: 397,2 m³ Water ballast: 18.996,9 m³ |
|
Cargo gear |
Gearless |
|
ISM & commercial manager |
Cyprus Sea Lines Co. Ltd. 349, Kifisias Avenue 145 61 Athens Greece |
|
Registered owner |
S Santiago Shipping SA 349, Kifisias Avenue 145 61 Athens Greece |
|
Renamed |
02/2022 Pumba Liberia, Monrovia - Call sign: 5LDK8 Owner: Pumbaa Shipping Inc. |
|
Latest data adjustment |
29 March 2020 |
