| Antwerpen 28 July 2008 |
|
Name |
MAX LINUS DEDE |
|
Previous name |
2007-2008 - Joanna Borchard |
|
Type |
Cellular containership - Semi hatch less |
|
IMO-number |
9354387 |
|
Call sign |
V2CL9 |
|
Flag |
Antigua & Barbuda |
|
Previous flag |
2007 Liberia |
|
Port of registry |
St. John's |
|
GT |
9.962 t |
|
Summer |
Summer: 11.433 t |
|
NT |
6.006 t |
|
Number of 20ft containers |
868 |
|
Container capacity at 14t |
585 |
|
Reefer plugs |
234 |
|
Length |
134,44 m overall 125,08 m registered |
|
Breadth |
22,50 m over all |
|
Draught |
Summer: 8,71 m |
|
Bridge |
28,85 m |
|
Forecastle |
62,54 m |
|
Poop |
9,45 m |
|
Freeboard |
2.590 mm |
|
Depth |
11,30 m moulded |
|
Speed |
18,5 knots |
|
Built |
2007 |
|
Keel laid |
06.12.2004 |
|
Launch date |
16.03.2007 |
|
Date of completed |
31.05.2007 |
|
Builder |
J.J. Sietas KG Schiffswerft GmbH & Co |
|
Yard number |
1237 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull Double bottom |
|
Watertight bulkheads |
4 |
|
Continuous decks |
1 |
|
Main engine |
1x Mak 9M43C - 4 stroke single acting 9 cylinder diesel 430 x 610 mm engine - 11.421 bhp / 8.400 kW Built: 2007 Manufacturer: Caterpillar Motoren GmbH & Co. KG Transmission: Main propulsion acts through gears on the propellershafts Starter type: Compressed air direct |
|
Propeller |
1x Controllable pitch propeller - aft |
|
Boilers |
1x Thermal oil heater, oil fired - 10,0 bar Heating surface: 45,2 m² Year of Manufacture: 2007 Manufacturer: PWT Prozess-Wärmeträgertechnik GmbH 1x Thermal oil heater, oil fired - 10,0 bar Heating surface: 45,4 m² Year of Manufacture: 2007 Manufacturer: ISW GmbH Industrie Service & Wärmeträgeranlagenbau 1x Thermal oil heater, exhaust gas heated - 10,0 bar Heating surface: 183,0 m² Year of Manufacture: 2007 Manufacturer: PWT Prozess-Wärmeträgertechnik GmbH 1x Thermal oil heater, exhaust gas heated - 10 bar Heating surface: 183,0 m² Year of Manufacture: 2007 Manufacturer: ISW GmbH Industrie Service & Wärmeträgeranlagenbau |
|
Electric installations |
1x 400 V - 2.545 kVA 1x 400 V - 1.860 kVA 1x 400 V - 400 kVA 1x 400 V - 192 Ah 1x 24 V - 280 Ah |
|
Shaft generator |
1x 1.860 kVA |
|
Generators |
1x Main diesel generatorset 1.390 kVA 1x Main diesel generatorset 1.155 kVA |
|
Emergency generator |
1x Diesel generatorset 400 kVA |
|
Batteries |
1x Battery for Emergency lighting - 192 Ah 2x Batteries for Start emergency engine each 140 Ah |
|
Bow thruster |
1x Transverse thruster - 750 kW forward |
|
Stern thruster |
1x Transverse thruster - 450 kW aft |
|
Compressed air receivers |
2x Receivers, each 750 litres - 30,0 bar 1x Receiver 10 litres - 30,0 bar 1x Receiver 500 litres - 11,0 bar |
|
Anchor equipment |
3x Anchors weight each 5.250 kg Chain length: 577,50 m |
|
Cargo gear |
Gearless |
|
Crew size |
19 |
|
Manager |
Reederei Dede |
|
Shipping company |
Reederei Friedhelm Dede KG |
|
Owner |
MS "MAX LINUS DEDE" GmbH & Co. KG |
