Westerschelde 06 April 2020 |
 |
 |
 |
||
| Zeebrugge 01/06/12 | Westerschelde 29/06/20 | Westerschelde 13/07/20 | ||
|
Name |
JORK |
|
Previous names |
2001 - 03/12/2007 Margaretha |
|
Type |
Cellular containership |
|
IMO-number |
9234991 |
|
Call sign |
P3CJ9 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
GT |
9.981 t |
|
DWT |
11.385 t |
|
NT |
6.006 t |
|
Light ship |
4.228 t |
|
Number of 20ft containers |
868 |
|
Container capacity 14t |
610 |
|
Reefer point |
On deck: 54 In holds: 96 Total: 150 |
|
Length |
134,53 m overall 125,08 m between perpendiculars |
|
Breadth |
22,75 m overall 22,50 m registered |
|
Draught |
8,70 m |
|
Air draft |
40,45 m |
|
Freeboard |
2.609 mm |
|
Depth |
11,30 m moulded |
|
Speed |
18,5 knots |
|
Built |
2001 |
|
Keel laid |
26/06/2000 |
|
Launch date |
01/08/2001 |
|
Date of completion |
09/2001 |
|
Builder |
J.J. Sietas KG Schiffswerft GmbH & Co. Neuenfelder Fährdeich 88 21129 Hamburg Federal Republic of Germany |
|
Yard number |
1192 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Single hull Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
7 |
|
Continuous decks |
2 |
|
Main engine |
1x MaK 9M43 - 4 stroke 9 cylinder 430 x 610 mm combustion engine 8.400 kW / 11.413 hp at 500 rpm Reduction power: 7.950 kW Year of manufacture: 06/2004 Manufacturer: Caterpillar Motoren GmbH & Co. KG Falckensteiner Str. 2 24159 Kiel Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 130 rpm |
|
Electric installations |
2x Plant each 380/220 V - 625 kVA 1x Plant 380 V - 1625 kVA 1x Plant 380 V - 290 kVA |
|
Boilers |
1x Thermal oil heater, oil fired - 10,0 bar Heating surface: 52,0 m² 1x Thermal oil heater, exhaust gas heated - 10,0 bar Heating surface: 208,0 m² Year of manufacture: 2001 Manufacturer: PWT Prozesswärmeträgertechnik GmbH Max-Weber-Str. 10 25451 Quickborn Federal Republic of Germany |
|
Shaft generator |
1x SAM SE 500 - 1.300 kW / 1.625 kVA |
|
Generators |
2x Caterpillar 3412 DI TA diesel each 534 kW connected with generators each 625 kVA |
|
Emergency generator |
1x Caterpillar 3406 diesel engine 250 kW connected with generator 290 kVA |
|
Compressed air receivers |
2x Receivers each 750 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster Brunvoll - 750 kW forward 1x Transverse thruster Brunvoll - 450 KW aft |
|
Number of hatches |
2 Hatch 1: 12,37 x 12,37 m Hatch 2: 13,30 x 18,62 m |
|
Tank capacities |
Fuel oil: 920 m³ / 818 t Gas oil: 107 t Ballast water: 4.033 m³ Fresh water: 128 m³ |
|
Anchor equipment |
3x Anchors weight each 5.250 kg Chain length: 577,50 m |
|
Cargo gear |
None |
|
Crew |
13 |
|
ISM& commercial manager |
Rambow Reederei Schoolpadd 17 21706 Drochtersen Germany |
|
Registered owner |
MS "JORK" Meyer Bereederungs GmbH & Co. KG Care of Rambow Bereederungs GmbH & Co KG (Reederei Rambow) Schoolpadd 17 21706 Drochtersen Germany |
|
Renamed |
041/2022 Elbskipper Cyprus; Limassol - Call sign: P3CJ9 Reg. owner: MS ''ELBSKIPPER'' GmbH & Co. KG |
|
Latest data adjustment |
04 June 2022 |
