| Antwerpen 18 April 2013 |
 |
 |
 |
 |
 |
||||
| Antwerpen 31/08/11 | Antwerpen 20/11/07 | Antwerpen 27/08/14 | Antwerpen 24/07/14 | Antwerpen 24/07/14 |
|
Name |
INDEPENDENT ACCORD |
|
Type |
Containership |
|
IMO-number |
9306237 |
|
Call sign |
A8MM4 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
15.345 t |
|
DWT |
20.955 t |
|
NT |
7.838 t |
|
Number of 20ft containers |
1.574 |
|
Container capacity at 14t |
1.065 |
|
Reefer containers |
250 |
|
Length |
168,06 m overall 158,25 m between perpendiculars |
|
Breadth |
27,80 m overall 25,30 m registered |
|
Draught |
Summer: 10,20 m |
|
Freeboard |
3.650 mm |
|
Depth |
13,50 m moulded |
|
Speed |
18,0 knots |
|
Built |
2007 |
|
Keel laid |
23.03.2007 |
|
Launch date |
01.06.2007 |
|
Date of completion |
15.10.2007 |
|
Builder |
Jiangsu Yangzijiang Shipyard |
|
Yard number |
YZJ2003-672C |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull Double bottom |
|
Watertight bulkheads |
6 |
|
Continuous decks |
1 |
|
Main engine |
1x Sulzer 7RT-Flex60C 2 stroke single acting 7 cylinder 600 x 2.250 mm diesel engine- 16.520 kW at 114,0 rpm Year of manufacture: 2007 Manufacturer: Hudong Heavy Machinery Co., Ltd. |
|
Number of screws |
1x Solid propeller (keyless) - aft at 114,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 9,0 bar Heating surface: 19,5 m² 1x Steam boiler, exhaust gas heated - 9,0 bar Heating surface: 103,0 m² Year of manufacture: 2007 Manufacturer: Alfa Laval Qingdao Ltd. |
|
Electric installations |
1x Plant 450/230 V - 4.430 kVA 1x Plant 450 V - 1.350 kVA 1x Plant 450 V - 175 kVA 1x Plant 24 V - 684 Ah |
|
Shaft generator |
1.350 kVA |
|
Main generators |
2x Main diesel generatorsets each 1.292 kW / 1.615 kVA 1x Main diesel generatorset 900 kW / 1.200 kVA |
|
Emergency generator |
1x Diesel generatorset 175 kVA |
|
Batteries |
2x Batteries for UPS navigation each 200 Ah 2x Batteries for automation each 92 Ah 2x Batteries for start emergency engine each 50 Ah |
|
Bow thruster |
1x Transverse thruster - 666 kW forward |
|
Stern thruster |
1x Transverse thruster - 750 kW aft |
|
Compressed air receivers |
2x Receivers each 6.300 litres - 30,0 bar 1x Receiver 250 litres - 30,0 bar 1x Receiver 500 litres - 12,0 bar |
|
Anchor equipment |
3x Anchors weight each 7.350 kg Chain length: 605,00 m |
|
Cargo gear |
Gearless |
|
Manager |
Norddeutsche Reederei H. Schuldt GmbH & Co. KG Federal Republic of Germany |
|
Operator |
ICL Independent Container Line |
|
Owner |
Zehnte Beteiligungs-KG TIM Shipping mbH & Co. |
|
Owner as completed |
Zehnte Beteiligungs-KG TIM Sg mbH & Co. |
|
Latest data adjustment |
10 October 2014 |
