Westerschelde 27 August 2018 |
 |
 |
 |
 |
|||
| Westerschelde 27/08/18 | Westerschelde 19/02/20 | Westerschelde 05/05/20 | Westerschelde 18/09/19 |
|
Name |
COSCO SHIPPING CAPRICORN |
|
Type |
Cellular containership |
|
IMO-number |
9783514 |
|
Call sign |
VRRU3 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
196.670 t |
|
DWT |
197.087 t |
|
NT |
92.071 t |
|
Number of 20ft containers |
20.038 |
|
Container capacity 14t |
13.400 |
|
Reefer capacity |
1.000 |
|
Length |
399,81 m overall 382,00 m between perpendiculars |
|
Breadth |
58,60 m moulded |
|
Draught |
Max: 17,00m |
|
Deckhouse |
7,20 m |
|
Freeboard |
7.351 mm |
|
Depth |
30,70 m moulded |
|
Speed |
Max: 22,5 knots Service: 19,0 knots |
|
Built |
2018 |
|
Keel laid |
07/12/2015 |
|
Launch date |
28/03/2018 |
|
Date of completion |
18/07/2018 |
|
Builder |
Nantong COSCO KHI Ship Engineering Co., Ltd. China |
|
Yard number |
NE233 |
|
Hull material |
Steel |
|
Bulkheads |
13 |
|
Main engine |
1x MAN-B&W/CSSC-MES Diesel 11S90ME-C10 - 2 stroke single acting 11 cylinder 900 x 3.260 mm combustion engine 54.950 kW / 74.710 hp at 72,0 rpm Built: 13/04/2017 Builder: Hyundai Heavy Industries Co Ltd - South Korea |
|
Propellers |
1x Fixed pitch propeller aft at 72,0 mm |
|
Boilers |
1x Exhaust gas eEconomiser 1x Water tube auxiliary boiler Built: 02/03/2017 Builder: Alfa Laval Qingdao Ltd. |
|
Generators |
2x Wärtsilä 7L25 - 4 stroke 7 cylinder 320 x 400 mm engines each 3.360 kW coupled with Hyundai HSJ7 805-10P generatorsets each 3.207 kW / 6.600 Volt - 60 Hz 2x Wärtsilä 9L32 - 4 stroke 7 cylinder 320 x 400 mm engines each 4.320 KW coupled with Hyundai HSJ7 805-10P generatorsets each 4.107 kW / 6.600 Volt - 60 Hz |
|
Bow thruster |
2x Each 1.500 kW / 2.039 bhp |
|
Number of holds |
10 |
|
Number of hatches |
1x 12,60 x 33,00 m 9x 12,60 x 53,60 m |
|
Tank capacities |
Water ballast: 64.232 m³ |
|
Cargo gear |
Gearless |
|
Commerical manager |
COSCO Shipping Lines Co Ltd. COSCO Plaza, 378, Dongdaming Lu, Hongkou Qu, Shanghai, 200080 China |
|
ISM manager |
Shanghai Ocean Shipping Co., Ltd. COSCO Plaza, 378, Dongdaming Lu, Hongkou Qu, Shanghai, 200080 China |
|
Registered owner |
COSCO Legend Shipping Ltd. Care of COSCO Shipping Lines Co., Ltd. COSCO Plaza, 378, Dongdaming Lu, Hongkou Qu Shanghai, 200080 China |
|
Latest data adjustment |
19 March 2022 |
