Westerschelde 24 October 2018 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 24/10/18 | Antwerpen 23/10/18 | Westerschelde 14/04/20 | Westerschelde 14/04/20 | Westerschelde 22/05/18 | Westerschelde 22/05/18 | |||||
|
Name |
COSCO SHIPPING GEMINI |
|
Type |
Cellular containership |
|
IMO-number |
9783526 |
|
Call sign |
VRRO3 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
195,342 |
|
DWT |
202.024,7 t |
|
NT |
108.694 |
|
Number of 20ft containers |
In hold: 8.475 On deck: 11.644 Total: 20.119 |
|
Container capacity 14t |
13.400 |
|
Reefer plug |
1.000 |
|
Length |
399,88 m overall 383,06 m between perpendiculars |
|
Breadth |
58,72 m extreme 58,60 m moulded |
|
Draught |
Max: 16,00 m |
|
Forecastle |
384,20 m |
|
Deckhouse |
6,30 m |
|
Freeboard |
7.309 mm |
|
Depth |
30,50 m |
|
Speed |
Max: 22,5 knots Service: 19,0 knots |
|
Built |
2018 |
|
Keel laid |
25/12/2015 |
|
Launch date |
18/10/2017 |
|
Date of completion |
10/04/2018 |
|
Builder |
Chinese Shipyard Dalian Shipbuilding Industry Co., Ltd. Dalian China |
|
Yard number |
C20K-1 |
|
Hull material |
Steel |
|
Bulkheads |
14 |
|
Number of decks |
2 Upper Deck & 2nd Deck |
|
Main engine |
1x MAN-B&W/CSSC-MES Diesel 11S90ME-C9&10 - 2 stroke single acting 11 cylinder 900 x 3.260 mm combustion engine 55.000 kW / 74.778 hp at 72,0 rpm Built: 12/05/2017 Builder: CSSC-MES Diesel Co.,Ltd.,Shanghai - China |
|
Propellers |
1x Fixed pitch propeller - aft at 72,0 rpm |
|
Boilers |
2x Auxiliary boiler, exhaust gas heated - Aalborg XS-7V 1x Auxiliary boiler, oil/gas fired - Aalborg OS-6500 Built: 26/04/2017 Builder: Alfa Laval Qingdao Ltd. |
|
Generators |
2x MAN 9L32/40CD - 4 stroke 7 cylinder 320 x 400 mm diesel engines each 3.500 kW connected with 2 generators each 3.400 kW / 6.600 Volt 2x MAN 7L32/40CD - 4 stroke 9 cylinder 320 x 400 mm diesel engines each 4.400 kW connected with 2 generators each 4.300 kW / 6.600 Volt |
|
Emergency generator |
1x Scania DI13 diesel generatorset |
|
Bow thruster |
2x 2.500 kW / 3.399 bhp, forward |
|
Number of holds |
22 |
|
Number of hatches |
20x 12,60 x 53,60 m 1x 12,60 x 48,29 m 1x 12,60 x 38,21 m |
|
Tank capacities |
Ballast: 49.614 m³ |
|
Anchor equipment |
Length: 770,00 m Diameter: 137 |
|
Lifting equipment |
1x Crane - SWL 12,5 t 1x Crane - SWL 09 t 2x Engine room overhead cranes - SWL 15,5 t each 1x Provision crane - SWL 4,2 t |
|
Cargo gear |
Gearless |
|
Crew size |
32 |
|
Commercial manager |
COSCO Shipping Lines Co Ltd. COSCO Plaza, 378, Dongdaming Lu, Hongkou Qu, Shanghai, 200080 China |
|
ISM manager |
Shanghai Ocean Shipping Co Ltd. COSCO Plaza, 378 Dongdaming Lu, Hongkou Qu Shanghai, 200080 China |
|
Registered owner |
COSCO Happiness Shipping Ltd. c/o COSCO Shipping Lines Co Ltd. COSCO Plaza, 378, Dongdaming Lu, Hongkou Qu, Shanghai, 200080 China |
|
Latest data adjustment |
19 November 2025 |
