Westerschelde 15 January 2017 |
 |
| WS 15/01/17 |
|
Name |
DELPHIS BOTHNIA |
|
Type |
Cellular containership |
|
IMO-number |
9763710 |
|
Call sign |
VRPU4 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
25.715 t |
|
DWT |
24.700 t |
|
NT |
7.715 t |
|
Number of 20ft containers |
1.926 |
|
Length |
177,56 m overall 169,52 m between perpendiculars |
|
Breadth |
30,54 m extreme |
|
Draught |
9,50 m |
|
Freeboard |
2.478 mm |
|
Depth |
16,80 m |
|
Speed |
Max.: 18,0 knots |
|
Built |
2016 |
|
Keel laid |
21.12.2015 |
|
Launch date |
14.04.2016 |
|
Date of completion |
29.08.2016 |
|
Builder |
Hanjin Heavy Industries & Construction Co., Ltd. |
|
Yard number |
263 |
|
Hull material |
Steel |
|
Main engine |
1x MAN-B&W 6S60ME-C8 - 6 cylinder diesel engine 14.280 kW |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary boiler, composite (Composite Boiler) Builder: Kangrim Heavy Industries Co.,Ltd. |
|
Generators |
3x HimSen 8H21/32 main diesel generatorsets 1x HimSen 6H21/32 main diesel generatorset Builder: Hyundai Heavy Industries Co., Ltd. |
|
Emergency generator |
1x Cummins 855 diesel generatorset |
|
Bow thruster |
1.100 kW, forward 515 kW, stern |
|
Tank capacities |
Ballast: 10.249,09 m³ |
|
Anchor equipment |
Length: 660,00 m Diameter: 76 mm |
|
Crew |
14 |
|
Manager |
Anglo-Eastern (Germany) GmbH |
|
Operator |
Delphis N.V. Schaliënstraat 3 |
|
Registered owner |
Alpha Vessel Ltd. |
|
Latest data adjustment |
14 May 2017 |
