Westerschelde 27 October 2018 |
 |
 |
 |
||
| Antwerpen 05/01/17 | Antwerpen 05/01/17 | Westerschelde 21/09/16 |
|
Name |
HAMMONIA HUSUM |
|
Previous names |
2006 - 10/2011 Libra Copacabana |
|
Type |
Cellular containership - Handymax |
|
IMO-number |
9326835 |
|
Call sign |
A8IM8 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
26.836 t |
|
DWT |
Summer: 34.253,7 t |
|
NT |
12.743 t |
|
Number of 20ft containers |
2.558 |
|
Number of 40ft containers |
1.240 |
|
Container capacity 14t |
1.850 |
|
Reefer plugs |
600 |
|
Length |
210,09 m overall 199,00 m between perpendiculars |
|
Breadth |
30,23 m extreme |
|
Draught |
11,50 m |
|
Forecastle |
26,45 m |
|
Quarterdeck |
38,53 m |
|
Depth |
16,70 m |
|
Speed |
21,5 knots |
|
Built |
2006 |
|
Keel laid |
10/11/2005 |
|
Launch date |
31/03/2006 |
|
Date of completion |
11/05/2006 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. Ulsan South Korea |
|
Yard number |
H1756 |
|
Watertight bulkheads |
7 |
|
Continuous decks |
1 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Main engine |
1x Sulzer 7RTA72U-B - 2 stroke 7 cylinder 720 x 2.500 mm combustion engine 21.560 kW at 99,0 rpm Built: 2005 Manufacturer: Hyundai Heavy Industries Co., Ltd. |
|
Propellers |
1x Fixed propeller keyless - aft at 99,0 rpm |
|
Boilers |
1x Steam boiler, oil fired / exhaust gas heated - 7,85 bar Heating surface 30,0 m² Heating surface 304,0 m² Built: 2005 Manufacturer: KangRim Industries Co., Ltd. (3rd Factory) |
|
Electric Installations |
1x Plant 450/230 V - 2133.3 kVA 1x Plant 450/230 V - 2133.3 kVA 1x Plant 450/230 V - 2133.3 kVA 1x Plant 450/230 V - 2133.3 kVA 1x Plant 450 V - 250 kVA 1x Plant 24 V - 50 Ah 1x Plant 24 V - 200 Ah 1x Plant 24 V - 300 Ah |
|
Generators |
4x MAN-B&W 8L28/32H main diesel generatorsets each 1.693 kW - 2.133,3 kVA |
|
Emergency generator |
1x Sisu 645 DSBAG diesel generatorset 250 kVA |
|
Batteries |
1x Battery for emergency lighting 300 Ah 2x Batteries for UPS radio each 200 Ah 2x Batteries for start emergency engine each 50 Ah |
|
Compressed air receivers |
2x Receivers each 5.000 litres - 30 bar 1x Receiver 250 litres - 30 bar 1x Receiver 2.000 litres - 8,8 bar 1x Receiver 200 litres - 8,3 bar |
|
Bow thruster |
1x Transverse thruster 1.000 kW, forward |
|
Tank capacities |
Ballast: 9.456,9 m³ |
|
Anchor equipment |
3x Anchors weight each 9.300 kg Length: 660,00 m Diameter: 76 mm |
|
Cargo gear |
4x Cranes - SWL 40,0 t each |
|
Manager |
Hammonia Reederei GmbH & Co. KG Elbchaussee 370 22609 Hamburg Germany |
|
Operator |
Peter Döhle Schiffahrts-KG Elbchaussee 370 22609 Hamburg Germany |
|
Registered owner |
HSL Husum Shipping Limited |
|
Latest data adjustment |
23 December 2019 |
