Westerschelde |
 |
 |
|
| Westerschelde 14/07/16 | Antwerpen 23/10/18 | |
|
Name |
MERETE MAERSK |
|
Type |
Cellular containership - Carriage of dangerous goods |
|
IMO-number |
9632064 |
|
Call sign |
OWQZ2 |
|
Flag |
Denmark |
|
Port of registry |
Sundby |
|
GT |
194.849 t registered Suez: 199.185,85 t |
|
DWT |
Summer: 194.915,6 t |
|
NT |
79.120 t registered Suez: 174.365,66 t |
|
Number of 20ft containers |
18.270 |
|
Length |
399,20 m overall 376,21 m between perpendiculars |
|
Breadth |
59,00 m moulded |
|
Draught |
16,50 m |
|
Freeboard |
6.845 mm |
|
Depth |
30,30 m moulded |
|
Speed |
22,0 knots |
|
Built |
2014 |
|
Keel laid |
11/02/2014 |
|
Launch date |
20/04/2014 |
|
Delivery date |
22/08/2014 |
|
Builder |
Daewoo Shipbuilding & Marine Engineering Co., Ltd. Geoje South Korea |
|
Yard number |
4262 |
|
Hull material |
High strength steel |
|
Watertight bulkheads |
16 |
|
Main engine |
2x MAN-B&W/Doosan 7S80ME-C - 7 cylinder 800 x 3.450 mm combustion engine each 23.310 kW / 31.692 hp at 72,0 rpm Total: 43.620 kW / 63.384 hp Manufacturer: Doosan Engine Co., Ltd. |
|
Propellers |
2x Fixed pitch propeller 4 blades - diameter 9,80 m Manufacturer: Mecklenburger Metallguss GmbH |
|
Boilers |
2x Exhaust gas economizer - 12,5 bar 2x Exhaust gas economizer - 14,0 bar 2x Exhaust gas economizer - 8,0 bar 1x Auxiliary boiler - 9,0 bar |
|
Shaft generator |
2x 3.000 kW each Manufacturer: Siemens AG |
|
Turbo generator |
1x 6.000 kW (Brotherhood combi turbine exhaust gas/Steam) Manufacturer: HHI Electro Electric System |
|
Generators |
3x Main diesel generatorsets each 2.800 kW Manufacturer: HHI Electro Electric System |
|
Number of holds |
11 |
|
Hold capacity |
384.683,6 m³ |
|
Number of tanks |
Ballast: 38 Lubricating oil: 15 Fuel oil: 13 Fresh water: 8 Waste water: 6 Diesel oil: 4 Sludge: 4 Chain: 2 |
|
Tank capacities 100% |
Diesel Oil: 1.100,8 m³ Freshwater: 1048,3 m³ Fuel Oil: 14.018,6 m³ Lube Oil: 588,6 m³ Tank Ballast: 63.173,2 m³ |
|
Lifting equipment |
2x Engine room crane - SWL 10,0 t each 1x Monorail crane - SWL 12,5 t each 2x Provision crane - SWL 2,0 t each Manufacture: Dongnam Marine Crane Co., Ltd. |
|
Cargo gear |
Gearless |
|
Operator |
Maersk Line A/S Esplanaden 50 DK-1263 Copenhagen K Denmark |
|
Registered owner |
Maersk Line A/S |
|
Latest data adjustment |
08 October 2023 |
