Westerschelde 13 October 2016 |
 |
 |
 |
||
| Westerschelde 20/05/16 | Antwerpen 07/07/16 | Westerschelde 04/07/16 | ||
|
Name |
NOR FEEDER |
|
Previous names |
03/1998 - 11/2006 Jan Fabian 11/2006 - 02/2018 Nor feeder |
|
Type |
Containership - Feeder |
|
IMO-number |
9144689 |
|
Call sign |
LAWT7 |
|
Flag |
Norway |
|
Port of registry |
Haugesund |
|
Previous flags |
1998 - 2003 Germany, Hamburg - Call sign: DGF5 2003 - 2006 United Kingdom, London 2006 - 2015 Gibraltar - Call sign: ZDHT9 |
|
GT |
3.999 t |
|
DWT |
Summer: 5.202 t |
|
NT |
2.176 t |
|
Number of 20ft containers |
In hold: 143 On deck: 365 Total: 508 |
|
Reefer capacity |
68 |
|
Length |
101,15 m overall 96,00 m between perpendiculars 96,13 m registered |
|
Breadth |
18,20 m extreme |
|
Draught |
Summer: 6,55 m |
|
Forecastle |
9,33 m |
|
Poop |
9,00 m |
|
Freeboard |
1.700 mm |
|
Depth |
8,25 m moulded |
|
Speed |
15,3 knots |
|
Built |
1998 |
|
Keel laid |
07/12/1995 |
|
Launch date |
17/02/1998 |
|
Date of completion |
01/03/1998 |
|
Builder |
J.J. Sietas KG Schiffswerft GmbH & Co. Neuenfelder Fährdeich 88 21129 Hamburg Federal Republic of Germany |
|
Yard number |
1139 |
|
Hull material |
Shipbuilding steel (standard) |
|
Watertight bulkheads |
5 |
|
Continuous decks |
1 |
|
Main engine |
1x MAK 9M32 - 4 stroke single acting 9 cylinder 320 x 480 mm combustion engine 3.825 kW / 5.197 bhp Year of manufacture: 1998 Manufacturer: Krupp Mak Maschinenbau GmbH Falckensteiner Str. 2 24159 Kiel Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - aft |
|
Electric installations |
1x 380/220 V - 640 kVA 1x 380 V - 850 kVA 1x 380 V - 40 kVA |
|
Shaft generator |
1x 850 kVA |
|
Generators |
2x Caterpillar 3408 DITA diesel generatorsets each 320 kVA |
|
Emergency generator |
1x Deutz F5L912 diesel generatorset 40 kVA |
|
Compressed air receivers |
2x Receivers, each 500 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster JASTRAM - 400 kW, forward |
|
Cargo capacity |
Bale: 7.013 m³ Grain: 7.247 m³ |
|
Number of holds |
2 |
|
Number of hatches |
3 Hatch 1: 6,30 x 12,90 m Hatch 2: 25,00 x 15,52 m Hatch 3: 25,20 x 15,52 m |
|
Tank capacities |
Ballast: 2.161,39 m³ |
|
Anchor equipment |
3x Anchors weight each 3.300 kg Length: 495,00 m Diameter: 46 mm |
|
Manager |
Arriva Shipping AS Bjoavegen 389 5582 Ølensvåg Norway |
|
Previous managers |
1998 - 2006 Reederei Heinz-Georg Voge K.G., Drochtersen - Germany 2006 - 2015 Karmoy Skipconsult Management AS |
|
Owner |
Arriva Shipping AS Olen Norway |
|
Previous names & owners |
03/1998 - 11/2006 Jan Fabien - m.s. Jan Fabian Heinz-Georg Voge K.G., Drochtersen - Germany 11/2006 - 2015 Nor Feeder - Rederi Sandfrakt AS, Olen - Norway |
|
Renamed |
05/02/2018 A2B Spirit The Netherlands, Moerdijk - Call sign: PCBE Owner: A2B-Online 5 B.V., Moerdijk - The Netherlands Manager: A2B-Online Ship Management B.V, Moerdijk - The Netherlands |
|
Latest data adjustment |
02 October 2020 |
