Westerschelde 28 July 2012 |
 |
 |
 |
||
| Westerschelde 18/07/12 | Westerschelde 10/02/16 | Westerschelde 06/06/17 | ||
|
Name |
MSC SHANGHAI |
|
Previous names |
Build as: Santa Viola |
|
Type |
Cellular containership |
|
IMO-number |
9295373 |
|
Call sign |
A8HO3 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
65.483 |
|
DWT |
Summer: 72.064 t |
|
NT |
37.611 |
|
Number of 20ft containers |
5.962 |
|
Container capacity 14t |
4.382 |
|
Reefer capacity |
400 |
|
Length |
274,68 m overall 263,00 m between perpendiculars |
|
Breadth |
40,00 m extreme |
|
Draught |
14,50 m |
|
Freeboard |
5.680 mm |
|
Depth |
24,20 m moulded |
|
Speed |
Max.: 26,1 knots |
|
Service |
North Europe Service 1 |
|
Built |
2005 |
|
Keel laid |
04/04/2005 |
|
Launch date |
17/06/2005 |
|
Date of completion |
25/08/2005 |
|
Builder |
Hyundai Samho Mokpo Shipyard Co., Ltd. Mokpo South Korea |
|
Yard number |
S229 |
|
Hull material |
Steel |
|
Hull type |
Single hull Double bottom |
|
Watertight bulkheads |
9 |
|
Main engine |
1x Hyundai/MAN-B&W 10K98MC-C - 2 stroke 10 cylinder 980 x 2.400 mm combustion engine 57.100 kW / 77.600 bhp at 104,0 rpm Year of manufacture: 2005 Manufacturer: Hyundai Heavy Industries Co., Ltd. 1, Jeonha-dong, Dong-gu Ulsan, 682-792 Kyongsang-namdo Republic of Korea |
|
Propellers |
1x Solid propeller (keyless) - aft 104,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 10,0 bar Heating surface: 40,1 m² 1x Steam boiler, exhaust gas heated - 10,0 bar Heating surface: 914,0 m² Year of manufacture: 2004 Manufacturer: Alfa Laval Qingdao Ltd. 86 Guangzhou Road North Jiaozhou Qingdao, 266300 Shandong People's Republic of China |
|
Electric installations |
4x Plants each 440/ 230 V - 2.493,8 kVA 1x Plant 440 V - 625 kVA 1x Plant 12 V - 20 Ah 1x Plant 12 V - 60 Ah 1x Plant 24 V - 200 Ah 1x Plant 24 V - 500 Ah |
|
Generators |
4x Man 7L27/38 diesel generatorsets each 2.493,8 kVA / 1.995 kW |
|
Emergency generator |
1x Cummins VTA-28-D(M) diesel generatorset 625 kVA |
|
Batteries |
12x Batteries for emergency lighting each 200 Ah |
|
Compressed air receivers |
2x Receivers each 22.000 litres - 30,0 bar 2x Receivers each 250 litres - 30,0 bar 1x Receiver 200 litres - 7,7 bar |
|
Bow thruster |
1x Transverse thruster 2.500 kW, forward |
|
Anchor equipment |
3x Anchors weight each 16.100 kg Length: 742,50 m Diameter: 97 mm |
|
Cargo gear |
Gearless |
|
Previous managers |
2005 - 2015 Reederei Claus-Peter Offen (GmbH & Co.) KG |
|
Operator |
MSC - Mediterranean Shipping Company |
|
Registered owner |
Santa Viola Shipping Corp. |
|
Previous owners |
2005 - 2007 Kommanditgesellschaft MS "SANTA VIOLA" Offen Reederei GmbH & Co. |
|
Renamed |
08/2017 Santa Viola Malta, Valletta - Call sign: 9HA5885
|
|
Latest data adjustment |
05 April 2025 |
