Name |
EM CORFU |
|
Previous names |
2001 - 11.2006 Donata Schulte 11/2006 - 03/2013 Maersk Nairobi |
|
Type |
Self-sustained cellular containership |
|
IMO-number |
9231494 |
|
Call sign |
V7HF9 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
Previous flag |
2001 - 2018 Cyprus, Limassol - Call sign: P3CF9 |
|
GT |
26.582 t Suez: 27.589,96 t |
|
DWT |
Summer: 34.649 t |
|
NT |
12.715 t Suez: 22.566,89 t Panama: 23.521 t |
|
Light ship |
3.581 t |
|
Displacement |
45.725 t |
|
Number of 20ft containers |
In hold: 944 On deck: 1.612 Total: 2.556 |
|
Container capacity 14t |
1.850 |
|
Reefer capacity |
600 |
|
Length |
210,07 m overall 200,55 m registered 199,00 m between perpendiculars |
|
Breadth |
30,27 m moulded |
|
Draught |
Summer: 11,52m |
|
Keel to mast end |
51,98 m |
|
Forecastle |
26,37 m |
|
Poop |
38,50 m |
|
Depth |
16,70 m moulded |
|
Speed |
21,9 knots |
|
Built |
2001 |
|
Keel laid |
14/05/2001 |
|
Launch date |
18/08/2001 |
|
Date of completion |
12/10/2001 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. 1, Cheonha-dong, Dong-gu Ulsan Republic of Korea |
|
Yard number |
1306 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
8 |
|
Continuous decks |
1 |
|
Main engine |
1x Hyundai/Sulzer 7RTA72U-B - 2 stroke 7 cylinder 720 x 2.500 mm diesel engine Mcr 21.572 kW / 29.329 bhp at 99,0 rpm Year of manufacture: 2001 Manufacturer: Hyundai Engine & Machinery Co., Ltd. Ulsan Republic of Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 99,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 7,8 bar Heating surface: 30,0 m² 1x Steam boiler, exhaust gas heated - 7,8 bar Heating surface: 304,0 m² Year of manufacture: 2001 Manufacturer: KangRim Industries Co., Ltd. (1st Factory) Busan Republic of Korea |
|
Electric installations |
4x Plants each 440/220 V - 2.000 kVA 1x Plant 440 V - 188 kVA |
|
Generators |
4x MAN-B&W/Hyundai 8L28/32H main diesel generatorsets each 2.000 kVA / 1.680 kW |
|
Emergency generator |
1x MAN D 2866 TE diesel generatorset 188 kVA |
|
Compressed air receivers |
2x Receivers each 5.000 litres - 30,0 bar 1x Receiver 250 litres - 30,0 bar 1x Receiver 2.000 litres - 8,8 bar 1x Receiver 200 litres - 8,8 bar |
|
Bow thruster |
1x Transverse fixed pitch thruster Kawasaki 1.000 kW / 1.360 bhp, forward |
|
Number of holds |
5 |
|
Number of hatch |
5 |
|
Ventilation |
6x Electrically air-changes/hour |
|
Tank capacities |
Fuel: 3.918 m³ Water ballast: 9.463,5 m³ |
|
Anchor equipment |
3x Anchors weight each 9.300 kg Chain length: 660,00 m Diameter: 76 mm |
|
Cargo gear |
4x Cranes - SWL 45,0 t each outreach 14,40 m |
|
Crew size |
27 |
|
ISM & commercial manager |
Eurobulk Ltd. 4, Messogiou & Evropis Streets 151 24 Marousi Greece |
|
Registered owner |
Corfu Navigation Ltd. Care of Eurobulk Ltd , 4, Messogiou Street & Evropis Street Marousi 151 24 Athens Greece |
|
Latest data adjustment |
07 November 2021 |
