Cadiz, Spain 16 September 2014 |
 |
 |
|
| Cadiz, Spain 16/09/14 | Cadiz, Spain 10/09/14 |
|
Name |
MAERSK WEYMOUTH |
|
Type |
Cellular containership |
|
IMO-number |
9410260 |
|
Call sign |
VRFS9 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
18.123 t |
|
DWT |
Summer: 22.314 t |
|
NT |
7.996 t |
|
Number of 20ft containers |
1.713 |
|
Reefer capacity |
377 |
|
Length |
172,00 m overall |
|
Breadth |
27,90 m |
|
Draught |
9,53 m |
|
Reg. Dimensions L x B x D |
166,23 X 27,90 X 13,80 m |
|
Rule Dimensions L x B x D |
164,90 X 27,90 X 13,80 m |
|
Freeboard |
4.326 mm |
|
Depth |
13,80 m |
|
Speed |
Max.: 19,8 knots |
|
Built |
2009 |
|
Keel laid |
28.11.2008 |
|
Launch date |
04.08.2009 |
|
Date of completion |
15.10.2009 |
|
Builder |
CSBC Corporation, Taiwan Keelung Yard, Keelung - Taiwan |
|
Yard number |
H-940 |
|
Hull material |
Steel |
|
Watertight bulkheads |
Transverse: 11 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W-HHI 7S60MC-C - 2 stroke single acting 7 cylinder 600 x 2.400 mm diesel engine - 15.820 kW at 105,0 rpm Built: 03.2009 Builder: Hyundai Heavy Ind. Engine & Machinery, Ulsan - South Korea |
|
Propellers |
1x Solid propeller |
|
Boilers |
Built: 03.2009 Builder: Alfa Laval Qingdao Ltd., Qing Dao - China |
|
Generators |
3x Main diesel generatorsets each 1.875 kVA - 450 Volt |
|
Bow thruster |
1x 800 kW |
|
Hatchway number & size |
5 Hatch 1: 12,60 x 10,28 m Hatch 2: 25,20 x 25,54 m Hatch 3: 25,20 x 25,54 m Hatch 4: 25,20 x 25,54 m Hatch 5: 12,60 x 25,54 m |
|
Tank capacity |
Fuel oil: 2.062 m³ Fresh water: 302,9 m³ Water ballast: 7.248,9 m³ |
|
Cargo gear |
2x Deck cranes - SWL 40,0 t each |
|
Manager |
Cido Shipping (H.K.) Co., Ltd. |
|
Technical manager |
Univan Ship Management Limited |
|
Operator |
Maersk Line |
|
Registered owner |
White Fig Shipping S.A. |
|
Latest data adjustment |
17 October 2014 |
