| Westerschelde 07 July 2017 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 07/12/16 | Zeebrugge 17/02/14 | Zeebrugge 28/04/14 | Zeebrugge 28/04/14 | Westerschelde 21/06/18 | Westerschelde 10/05/17 | |||||
 |
||||||||||
| Westerschelde 16/04/18 | ||||||||||
|
Name |
CONMAR GULF |
|
Previous names |
2007 - 2007 JRS Castor 2007 - 2008 Lomur 2008 - 2010 JRS Castor 2010 - 2012 JRS Alster |
|
Type |
Containership |
|
IMO-number |
9341964 |
|
Call sign |
CQAH7 |
|
Flag |
Portugal |
|
Port of registry |
Madeira |
|
Previous flag |
2007 - 2015 Cyprus, Limassol 2015 - 2018 United Kingdom, London - Call sign: 2FXW4 |
|
GT |
7.545 t |
|
DWT |
Summer: 8.146 t |
|
NT |
3.165 t |
|
Number of 20ft containers |
On deck: 472 In hold: 226 Total: 698 |
|
Container capacity 14t |
436 |
|
Reefer points |
120 |
|
Length |
129,56 m overall 119,95 m between perpendiculars |
|
Breadth |
20,60 m |
|
Draught |
7,40 m |
|
Forecastle |
8,53 m |
|
Poop |
9,87 m |
|
Freeboard |
3.411 mm |
|
Depth |
10,80 m |
|
Speed |
Max.: 16,5 knots Service: 15,9 knots |
|
Built |
2007 |
|
Keel laid |
29/12/2004 |
|
Launch date |
16/07/2007 |
|
Date of completion |
10/2007 |
|
Builder |
Fujian Mawei Shipbuilding Mawei China |
|
Yard number |
VMW 437-23 |
|
Hull material |
Steel |
|
Hull type |
Single hull double bottom, continuous from peak to peak bulkhead |
|
Watertight compartments |
6 |
|
Continuous decks |
1 |
|
Main engine |
1x Caterpillar/MaK 8M43C - 4 stroke 8 cylinder 430 x 610 mm combustion engine 7.200 kW / 9.783 hp at 500 rpm Manufacturer: Caterpillar Motoren GmbH & Co. KG |
|
Propellers |
1x Screw propeller controllable pitch - aft at 149 rpm |
|
Boilers |
1x Thermal oil heater, oil fired - 10,0 bar Heating surface: 35,80 m² 1x Thermal oil heater, exhaust gas heated - 10,0 bar Heating surface: 121,50 m² Manufacturer: ISW GmbH Industrie Service & Wärmeträgeranlagenbau |
|
Shaft generator |
1x 1.250 kVA - 1.000 kW |
|
Generators |
3x Main diesel generatorsets each 563 kVA - 450 kW - 679 hp |
|
Emergency generator |
1x 181 kVA |
|
Batteries |
2x Batteries for automation each: 200 Ah 2x Batteries for UPS radio each 143 Ah 2x Batteries for start emergency engine each 56 Ah |
|
Compressed air receivers |
2x Receivers each 1.000 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster 600 kW, forward |
|
Number of holds |
4 |
|
Total capacity of holds |
12.643,80 m³ |
|
Tank capacities |
Fuel oil: 663,3 m³ MGO: 112,9 m³ |
|
Anchor equipment |
3x Anchors weight each 4.590 kg Chain length: 550,00 m |
|
Cargo gear |
Gearless |
|
Crew size |
17 |
|
ISM & commercial manager |
Conmar Shipping GmbH & Co. KG Obstmarschenweg 11a 21635 Jork Germany |
|
Registered owner |
Schifffahrtsgesellschaft Conmar Gulf mbH & Co KG Obstmarschenweg 11A 21635 Jork Niederelbe Germany |
|
Latest data adjustment |
06 November 2022 |
