Niledutch Springbok - IMO 9222106

Name

NILEDUTCH SPRINGBOK

Previous names

Westermoor

Type

Cellular containership

IMO-number

9222106

Call sign

A8CH2

Flag

Liberia

Port of registry

Monrovia

GT

30.047 t

DWT

35.653 t

NT

12.671 t

Number of 20ft containers

2.672

Container capacity 14t

2.040

Reefer capacity

400

Length

207,94 m overall

195,48 m registered

Breadth

32,24 m registered

Draught

Max.: 11,50 m

Forecastle

33,69 m

Freeboard

5.336 mm

Depth

16,80 m

Speed

Max.: 22,2 knots

Built

2001

Keel laid

11.01.2001

Launch date

30.06.2001

Date of completion

14.08.2001

Builder

Stocznia Gdynia S.A.
ul. Czechoslowacka 3
81-969 Gdynia
Republic of Poland

Yard number

B8230/01

Hull material

Shipbuilding steel (higher tensile)

Hull type

Double bottom

Watertight bulkheads

8

Continuous decks

2

Main engine

1x MAN-B&W 8S70MC-C - 2 stroke 8 cylinder 700 x 2.800 combustion engine - 24.830 kW at 91,0 rpm

Year of manufacture: 2001

Manufacturer: H. Cegielski-Poznan S.A.
ul. 28 Czerwca 1956 223/229
60-965 Poznan
Republic of Poland

Propellers

1x Solid propeller (keyless) - aft at 91,0 rpm

Boilers

1x Thermal oil heater, oil fired - 10,bar

Heating Surface: 89,0 m²

1x Thermal oil heater, exhaust gas heated - 10,0 bar

Heating Surface: 410,0 m²

Year of manufacture: 2001

Manufacturer: MP Rohrverformungstechnik GmbH
Kirchstr. 15
57629 Norken
Federal Republic of Germany

Electric installations

2x Plants each 450 V - 1.250 kVA

2x Plants each 450 V - 1.495 kVA

1x Plant 440 V - 263 kVA

Generators

2x MAN-B&W 5L28/32H diesel generatorsets each 1.050 kW

2x MAN-B&W 6L28/32H diesel generatorsets each 1.260 kW

Emergency generator

1x Diesel generatorset 263 kVA

Compressed air receivers

2x Receivers each 8.500 litres - 30,0 bar

1x Receiver 1.500 litres - 8,0 bar

1x Receiver 50 litres - 8,0 bar

Bow thruster

1x Transverse thruster BRUNVOLL - 1.200 kW, forward

Tank capacities

Fuel oil: 3.756 m³

Water ballast: 14.557 m³

Anchor equipment

3x Anchors weight each 10.500 kg

Chain length: 660,00 m

Cargo gear

3x Cranes - SWL 45,0 t each

1x Crane - SWL 35,0 t

Manager

Hans Peterson & Söhne GmbH & Co. KG
Johannes-Wilhelm-Geiger Weg 8
24768 Rendsburg
Federal Republic of Germany

Operator

Niledutch

Registered owner

Westermoor Shipping GmbH & Co. KG
Johannes-Wilhelm-Geiger-Weg 8
24768 Rendsburg
Federal Republic of Germany

Last data update

24 December 2013
