Name |
MSC SORAYA |
|
Type |
Cellular Containership - Post-Panamax |
|
IMO-number |
9372494 |
|
Call sign |
3ESD8 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
66.399 t |
|
DWT |
73.262 t |
|
NT |
37.740 t |
|
Number of 20ft containers |
5.762 |
|
Container capacity 14t |
4.180 |
|
Reefer capacity |
632 |
|
Length |
277,30 m overall 260,93 m between perpendiculars |
|
Breadth |
40,00 m |
|
Draught |
14,52 m |
|
Keel to mast end |
60,00 m |
|
Freeboard |
9.848 mm |
|
Depth |
24,30 m |
|
Speed |
24,49 knots |
|
Built |
2008 |
|
Keel laid |
14/04/2008 |
|
Launch date |
18/05/2008 |
|
Date of completion |
16/07/2008 |
|
Builder |
Samsung Shipbuilding & Heavy Industries Ltd. Geoje South Korea |
|
Yard number |
1654 |
|
Hull material |
Steel |
|
Watertight compartments |
12 |
|
Continuous decks |
1 |
|
Main engine |
1x Doosan/MAN-B&W 9K98MC - 2 stroke single acting 9 cylinder 980 x 2.660 mm combustion engine 51.535 kW / 70.067 hp at 94,0 rpm Builder: Doosan Engine Co., Ltd., Changwon - South Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 94,0 mm |
|
Boilers |
1x CHR Kangrim 354,00 m² - 9,0 bar 1x CHO Kangrim 81,15 m² - 9,0 bar |
|
Generators |
4x Wärtsilä diesel generatorsets each 2.875 kVA - 2.300 kW - 3.587 hp at 1.500 rpm |
|
Emergency generator |
1x Cummins KH 500 GF diesel generatorset 625 kVA - 500 kW - 815 hp at 1.800 rpm |
|
Bow thruster |
1x Tunnel thruster 2.500 kW / 3.399 bhp, forward |
|
Number of holds |
8 |
|
Fuel capacity |
9.124,6 m³ |
|
Lifting equipment |
2x Cranes - SWL 4,0 t 2x Cranes - SWL 12,5 t |
|
Cargo gear |
None |
|
Commercial manager |
Mediterranean Shipping Co chemin Rieu 12-14, 1208 Geneva Switzerland |
|
ISM manager |
Mediterranean Shipping Co Srl. Via Francesco Ciampa 29 80063 Piano di Sorrento NA Italy |
|
Registered owner |
Compania Naviera Soraya S.A. Napoli Italy |
|
Latest data adjustment |
01 February 2022 |
