Name |
LANGENESS |
|
Previous names |
2006 - 05/2007 Langeness 2007 - 05/2008 MSC Vilnius |
|
Type |
Cellular containership |
|
IMO-number |
9301134 |
|
Call sign |
V2EP6 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. Johns |
|
Previous flags |
05/2009 - 10/2009 Gibraltar - Call sign: ZDHT5 |
|
GT |
15.633 t |
|
DWT |
17.814 t |
|
NT |
7.059 t |
|
Number of 20ft containers |
In hold: 492 On deck: 910 Total: 1.402 |
|
Container capacity 14t |
870 |
|
Reefer capacity |
250 - whereof 120 in holds and 130 on deck |
|
Length |
160,83 m overall 151,00 m between perpendiculars |
|
Breadth |
25,52 m extreme 25,00 m moulded |
|
Draught |
10,15 m |
|
Height above keel |
50,20 m |
|
Forecastle |
33,39 m |
|
Poop |
28,98 m |
|
Freeboard |
4.015 mm |
|
Depth |
13,90 m moulded |
|
Speed |
20,1 knots |
|
Built |
2006 |
|
Keel laid |
16/12/2004 |
|
Launch date |
15/06/2006 |
|
Date of completion |
14/12/2006 |
|
Builder |
Shandong Province Weihai Shipyard 95 Haibin Road (N) 264200 Weihai , Shandong People's Republic of China |
|
Yard number |
CZ045 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
7 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 6S60MC-C - 2 stroke 6 cylinder 600 x 2.400 mm combustion engine 13.560 kW / 18.436 hp at 105,0 rpm Year of manufacture: 2006 Manufacturer: Hudong Heavy Machinery Co., Ltd. 2851, Pudong Dadao 200129 Shanghai People's Republic of China |
|
Propellers |
1x Solid propeller (keyless) - aft at 105,0 rpm |
|
Boilers |
1x Steam boiler, exhaust gas heated - 9,0 bar Heating surface: 349,0 m² Year of Manufacture: 2003 1x Steam boiler, oil fired - 9,0 bar Heating surface: 15,0 m² Year of Manufacture: 2005 Manufacturer: Alfa Laval Qingdao Ltd. 86 Guangzhou Road North Jiaozhou Qingdao, 266300 Shandong People's Republic of China |
|
Electric installations |
3x Plant each 450/230 V - 1.020 kVA 1x Plant 450 V - 250 kVA 1x Plant 24 V - 180 Ah 1x Plant 24 V - 195 Ah 1x Plant 24 V - 195 Ah |
|
Generators |
3x MaK 6M20 main diesel generatorsets each 1.020 kVA |
|
Emergency generator |
1x Diesel generatorset 250 kVA |
|
Batteries |
2x Batteries for emergency lighting each 195 Ah |
|
Compressed air receivers |
2x Receivers each 6.000 litres - 30,0 bar 1x Receiver 320 litres - 30,0 bar 1x Receiver 320 litres - 10,0 bar |
|
Bow thruster |
1x Transverse thruster - 800 kW, forward |
|
Number of holds |
4x Holds divided in 8 compartments Dimension: Hold 1: 24,15 x 15,70 x 17,20 m, narrowing Holds 2-6: 12,48 x 20,70 x 14,30 m Hold 7: 6,24 x 20,70 x 14,30 m |
|
Number of hatches |
8x Hatches with 14 hatch covers TTS pontoon type Dimensions: Hatches 1-2: 6,24 x 15,70 m Hatches 3-13: 6,24 x 20,70 m |
|
Hatch type |
Hatch covers are longitudinally divided for non-sequential opening and bay-wise operation also inside holds; it is not necessary to empty complete deck to reach containers in hold |
|
Tank capacities |
Fuel oil: 1.600 m³ Diesel oil: 150 m³ Ballast: 8.053,0 m³ Fresh water: 272,6 m³ |
|
Hold ventilation |
6x Air changes per hour |
|
Anchor equipment |
3x Anchors weight each 6.900 kg Chain length: 605,00 m Diameter: 64 mm |
|
Cargo gear |
2x Mac Gregor single deck container cranes: No. 1: 45 t / 26 m; 40 t / 29 m No. 2: 45 t / 31 m; 40 t / 35 m |
|
Crew size |
20 Persons - 20 cabins |
|
Manager |
Briese Schiffahrts GmbH & Co. KG Hafenstr. 12 26789 Leer Federal Republic of Germany |
|
Registered owner |
Briese Schiffahrts GmbH & Co. KG MS "LANGENESS" Hafenstr. 12 26789 Leer Federal Republic of Germany |
|
Renamed |
05/2022 Theodor Antigua and Barbuda, St. John’s - Call sign: V2EP6 Owner: Hermann Lohmann Schiffahrts GmbH & Co. KG MS "THEODOR” Manager: Hermann Lohmann Schiffahrtsverwaltung GmbH - Germany |
|
Latest data adjustment |
24 February 2024 |
