| Westerschelde 13 April 2016 |
 |
|
| Westerschelde 14/09/15 | |
|
Name |
NANSEN STRAIT |
|
Previous names |
07/2005 - 12/2005 P&O Nedlloyd Dover 12/2002 - 06/2010 Maersk Durham 09/2010 - 03/2012 Cap Stephens 03/2012 - 03/2015 Santa Philippa |
|
Type |
Cellular containership |
|
IMO-number |
9290426 |
|
Call sign |
D5GW9 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
07/2005 - 08/2014 Germany - Call sign: DCDP2 |
|
GT |
54.809 t |
|
DWT |
67.273 t |
|
NT |
34.226 t |
|
Number of 20ft containers |
5.042 |
|
Container capacity 14t |
3.370 |
|
Reefer capacity |
550 |
|
Length |
294,51 m overall 283,20 m between perpendiculars |
|
Breadth |
32,20 m |
|
Draught |
Summer: 13,65 m |
|
Keel to mast end |
53,55 m |
|
Forecastle |
141,90 m |
|
Bridge |
125,93 m |
|
Poop |
15,97 m |
|
Depth |
22,30 m |
|
Speed |
Max: 25,0 knots |
|
Built |
2005 |
|
Keel laid |
04/04/2005 |
|
Launch date |
10/06/2005 |
|
Date of completion |
26/07/2005 |
|
Builder |
Hyundai Heavy Industries Ulsan South Korea |
|
Yard number |
H 1568 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
9 |
|
Continuous decks |
1 |
|
Main engine |
1x Sulzer 8RTA96C-B - 2 stroke 8 cylinder 960 x 2.500 mm combustion engine 45.760 kW / 62.215 hp at 102,0 rpm Build: 2005 Manufacturer: Hyundai Heavy Industries Co., Ltd. |
|
Propellers |
1c Solid propeller (keyless) - aft at 102,0 rpm |
|
Boilers |
1x Steam boiler, oil fired 10,0 bar Heating surface: 26,8 m² 1x Steam boiler, exhaust gas heated - 10,0 bar Heating surface: 375,0 m² Build: 2005 Manufacturer: Alfa Laval Qingdao Ltd. |
|
Electric installations |
1x Plant 450/230 V - 2.137,5 kV 1x Plant 450/230 V - 2.137,5 kV 1x Plant 450/230 V - 2.850 kV 1x Plant 450/230 V - 2.850 kV 1x Plant 450 V - 313 kVA 1x Plant 24 V - 15 Ah 1x Plant 24 V - 24 Ah 1x Plant 24 V - 200 Ah 1x Plant 24 V - 200 Ah |
|
Generators |
2x Main diesel generatorsets each 2.850 kVA 2x Main diesel generatorsets each 2.137,5 kVA |
|
Emergency generator |
1x Diesel generatorset 313 kVA |
|
Batteries |
1x Battery for UPS radio 200 Ah 5x Batteries for diesel control each 24 Ah 1x Battery for start emergency engine 15 Ah |
|
Compressed air receivers |
2 Receivers each 11.500 litres - 30,0 bar 1 Receiver 250 litres - 30,0 bar 1 Receiver 60 litres - 30,0 bar 1 Receiver 250 litres - 8,8 bar 1 Receiver 2.000 litres - 8,0 bar |
|
Bow thruster |
1x Transverse thruster 2100 kW / 2.800 hp, forward |
|
Anchor equipment |
3x Anchors weight each 12.900 kg Chain length: 715,00 m |
|
Cargo gear |
Gearless |
|
Crew size |
32 |
|
Manager |
Carsten Rehder Schiffsmakler und Reederei GmbH & Co., KG Hamburg Germany |
|
Owner |
Offen Reederei Hamburg Germany |
|
Renamed |
2017 MSC Santa Maria Cyprus, Limassol - Call sign: 5BTQ4 Owner & Manager: Santa Maria Investments SA, Limassol - Cyprus 2022 MSC Santa Maria Republic of Panama, Panama City - Call sign: 3E3434 |
|
Latest data adjustment |
09 July 2023 |
