Sealand Washington - IMO 9196852

Name

SEALAND WASHINGTON

Type

Cellular Containership

IMO-number

9196852

Call sign

SVBY

Flag

Greece

Port of registry

Piraeus

GT

74.586 t

DWT

81.556 t

NT

41.490 t

Number of 20ft containers

6.252

Container capacity at 14t

4.826

Reefer capacity

500

Length

303,98 m overall
292,00 m between perpendiculars

294,11 m registered

Breadth

40,10 m over all

40,00 m registered

Draught

Summer: 14,00 m

Forecastle

147,06 m

Freeboard

6.180 mm

Depth

24,20 m

Speed

25,60 knots

Built

2000

Keel laid

08.03.2000

Launch date

10.06.2000

Date of completion

08.2000

Builder

Hyundai Heavy Ind. Co., Ltd.
1, Cheonha-dong, Dong-gu
Ulsan 682-792
Republic of Korea

Yard number

1210

Hull material

Shipbuilding steel (higher tensile)

Hull type

Single hull

Double bottom

Watertight bulkheads

9

Continuous decks

2

Main engine

1x MAN-B&W 10 K 98 MC-C - 2 stroke single acting 10 cylinder 980 x 2.400 mm diesel engine - 57.059 kW at 104,0 rpm

Year of manufacture: 2000

Manufacturer: Hyundai Engine & Machinery Co., Ltd.
Ulsan
Republic of Korea

Propellers

1x Solid propeller (keyless) - aft

Boilers

1x Steam boiler, oil fired - 7,8 bar

Heating surface: 68,0 m²

1x Steam boiler, exhaust gas heated - 9,8 bar

Heating surface: 455,0 m²

Year of manufacture: 2000

Manufacturer: KangRim Ind. Co., Ltd. (1st Factory)
505, Sinpyung-dong, Saha-gu
Busan
Republic of Korea

Electric installations

1x Plant 440/220 V - 11.400 kVA

1x Plant 440 V - 250 kVA

Generators

4x Main diesel generatorsets each 2.850 kVA

Emergency generator

1x Diesel generatorset 250 kVA

Compressed air receivers

2x Receivers each 13.500 litres - 30,0 bar

1x Receiver 250 litres - 30,0 bar

3x Receivers each 15 litres - 30,0 bar

1x Receiver 27 litres - 16,0 bar

1x Receiver 2.000 litres - 8,8 bar

1x Receiver 200 litres - 8,8 bar

Bow thruster

1x Transverse thruster KAWASAKI - 2.500 kW, forward

Anchor equipment

3x Anchors weight each 16.100 kg

Chain length: 742,50 m

Manager

Costamare Shipping Co., S.A.
60, Zephyrou St. Syngrou Ave.
175 64 Athens
Greece

Operator

Maersk

Owner

Christos Maritime Corp.
c/o Costamare Shipping Co., S.A.
60, Zephyrou St. Syngrou Ave.
175 64 Athens
Greece
