Westerschelde 15 September 2018 |
 |
| Westerschelde 11/03/19 |
|
Name |
JACOB |
|
Previous names |
2006 Launch as: Jacob Rickmers 05/2006 - 01/2014 CMA CGM Anapurna 01/2014 - 2017 Jacob Rickmers |
|
Type |
Cellular containership |
|
IMO-number |
9300166 |
|
Call sign |
V7FG6 |
|
Flag |
Marshall islands |
|
Port of registry |
Majuro |
|
Previous flags |
Saint Kitts & Nevis Portugal, Madeira - Call sign: CQFF |
|
GT |
21.971 t |
|
DWT |
Summer: 24.069 t |
|
NT |
8.588 t |
|
Number of 20ft containers |
1.858 |
|
Container capacity 14t |
1.300 |
|
Reefer capacity |
300 |
|
Length |
196,83 m overall 186,76 m registered |
|
Breadth |
27,80 m |
|
Draught |
Summer: 11,00 m |
|
Forecastle |
13,459 m |
|
Freeboard |
5.624 mm |
|
Depth |
16,60 m moulded |
|
Speed |
Max: 22,2 knots |
|
Built |
2006 |
|
Keel laid |
18/11/2004 |
|
Launch date |
15/02/2006 |
|
Date of completion |
15/06/2006 |
|
Builder |
Jiangsu Yangzijiang Shipbuilding Co., Ltd. 38 Shiyugang Road 214431 Jiangyin 100 People's Republic of China |
|
Yard number |
664C |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull, double bottom |
|
Continuous decks |
1 |
|
Main engine |
1x Hudong/MAN-B&W 6K80 MC-C - 2 stroke 6 cylinder 800 x 2.300 mm combustion engine 21.660 kW - 29.450 hp at 104,0 rpm Year of manufacture: 2005 Manufacturer: Hudong Heavy Machinery Co., Ltd. 2851, Pudong Dadao 200129 Shanghai People's Republic of China |
|
Propellers |
1x Solid propeller (keyless) - aft at 104,0 rpm |
|
Boilers |
1x Steam boiler, oil fired / exhaust gas heated - 10,0 bar Heating surface: 60,0 m² Heating surface: 786,0 m² Year of manufacture: 2005 Manufacturer: KangRim Industries Co., Ltd. (3rd Factory) 40, Wongnam-dong Changwon Republic of Korea 2x Steam boiler, steam drum - 8,62 bar Heating surface: 0,8 m² Year of manufacture: 2005 Manufacturer: KangRim Industries Co., Ltd. (1st Factory) Busan Republic of Korea |
|
Electric installations |
1x Plant 450/230 V - 1.125 kVA 3x Plant 450/230 V - 1.500 kVA 1x Plant 450 V - 220 kVA 1x Plant 24 V - 80 Ah 1x Plant 24 V - 100 Ah 1x Plant 24 V - 200 Ah |
|
Generators |
3x MAN 8 L23/30H diesel generatorsets each 1.200 kW / 1.500 kVA 1x MAN 6 L23/30H diesel generatorset 900 kW / 1.125 kVA |
|
Emergency generator |
1x D2866 TE diesel generatorset 220 kVA |
|
Batteries |
1x Emergency generator 200 Ah 2x Batteries for diesel control each 100 Ah 2x Batteries for start emergency engine each 80 Ah |
|
Compressed air receivers |
2x Receivers each 8.500 litres - 30,0 bar 1x Receiver 180 litres - 30,0 bar 1x Receiver 50 litres - 10,0 bar |
|
Bow thruster |
1x Transverse thruster 1.200 kW, forward |
|
Anchor equipment |
3x Anchors weight each 8.300 kg Chain length: 632,50 m |
|
Cargo gear |
2x Deck cranes - SWL 45,0 t each |
|
Crew |
23 |
|
Manager |
Hermes Maritime Services Pvt. Ltd. Great Easttern Summit B Plot 66 Sector 15CBD Belapur Navi Mumbai Maharashtra 400614 India |
|
Registered owner |
Jacob Maritime Ltd. |
|
Scrapped |
30/10/2019 Beached at Chittagong- Bangladesh under new name Paul |
|
Latest data adjustment |
07 March 2021 |
