| Westerschelde 05 February 2012 |
 |
| Westerschelde 27/09/12 |
|
Name |
ROSA |
|
Previous names |
07.2010 - 12.2011 Agros |
|
Type |
Cellular containership |
|
IMO-number |
9484534 |
|
Call sign |
D5AY3 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
42.112 t |
|
DWT |
54.338 t |
|
NT |
25.378 t |
|
Number of 20ft containers |
4.400 |
|
Container capacity 14t |
2.970 |
|
Reefer capacity |
360 |
|
Length |
260,34 m overall 247,29 m registered |
|
Breadth |
32,20 m registered |
|
Draught |
12,60 m |
|
Forecastle |
123,64 m |
|
Bridge |
114,04 m |
|
Freeboard |
3.890 mm |
|
Depth |
19,20 m moulded |
|
Speed |
24,37 knots |
|
Built |
2010 |
|
Keel laid |
09.04.2010 |
|
Launch date |
19.06.2010 |
|
Date of completion |
29.07.2010 |
|
Builder |
Daewoo Shipbuilding & Marine Engineering Co., Ltd. Okpo Shipyard |
|
Yard number |
4173 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom |
|
Watertight bulkheads |
8 |
|
Continuous decks |
2 |
|
Main engine |
1x MAN-B&W 8K90MC-C - 2 stroke 8 cylinder 900 x 2.300 diesel engine 36.560 kW at 104,0 rpm Year of manufacture: 2010 Manufacturer: Doosan Engine Co., Ltd. |
|
Propellers |
1x Solid propeller (keyless) - aft at 104,0 rpm |
|
Boilers |
1 x Steam boiler, oil fired - 9,0 bar Heating surface: 36,0 m² 1 x Steam boiler, exhaust gas heated - 9,0 bar Heating surface: 679,0m² Year of manufacture: 2009 Manufacturer: Alfa Laval Qingdao Ltd. |
|
Electric installation |
3x Plants each 450 V - 3.040 kVA 1x Plant 450 V - 375 kVA 1x Plant 12 V - 9 Ah 1x Plant 24 V - 2 Ah 1x Plant 24 V - 12 Ah 1x Plant 24 V - 12 Ah 2x Plants each 24 V - 92 Ah 1x Plant 24 V - 200 Ah 1x Plant 24 V - 215 Ah 1x Plant 24 V - 300 Ah 1x Plant 48 V - 24 Ah |
|
Generators |
3x Main diesel generators each 3.040 kVA / 2.432 kW |
|
Emergency generator |
1x Diesel generatorset 375 kVA |
|
Batteries |
1x Battery for UPS navigation - 300 Ah 2x Batteries for start emergency engine each 215 Ah 1x Battery for UPS radio - 200 Ah 2x Batteries for automation each 92 Ah 2x Batteries for other purpose each 24 Ah 1x Battery for diesel control - 12 Ah 2x Batteries for other purpose each 9 Ah 1x Battery for other purpose - 2 Ah |
|
Compressed air receivers |
2x Receivers each 11.000 litres - 33,0 bar 1x Receiver 300 litres - 33,0 bar 1x Receiver 300 litres - 8,0 bar |
|
Bow thruster |
1x Transverse thruster - 1.500 kW, aft |
|
Anchor equipment |
3x Anchors weight each 12.300 kg Chain Length: 687,50 m |
|
Cargo gear |
Gearless |
|
Crew size |
28 |
|
Manager |
Marlow Ship Management Deutschland GmbH & Co. KG |
|
Registered owner |
Rosa Navigation Co. Ltd. |
