Fortuny - IMO 9216585

Malaga, Spain 09 March 2016

Name

FORTUNY

Type

Roll-On/Roll-Off carrier - Ferry

IMO-number

9216585

Call sign

EBTO

Flag

Spain

Port of registry

Santa Cruz De Tenerife

GT

26.916

DWT

Summer: 4.834 t

NT

14.308

Length

172,60 m overall

157,00 m between perpendiculars

Breadth

26,20 m

Draught

6,20 m

Lane metres

1.809

Freeboard

3.012 mm

Depth

20,65 m

Speed

23,5 knots

Routes

• 06/2001 Valencia - Palma De Mallorca

• 10/2002 Cadiz - Canary Islands

• 20/2011 Valencia – Palma De Mallorca

• 02/2006 Bilbao - Portsmouth

• 02/2007 Cadiz – Canary Islands service

• Summer 2009 Barcelona – Palma

• Wnter 09/2010 Cadiz – Canary Island

• Summer 2010 Barcelona - Palma

• 06/2011 Barcelona – Palma and Valencia – Palma

• 02/2013 Cadiz – Canary Islands

• Summer 2015 Almeria – Melilla and Nalaga Melilla

Built

2001

Keel laid

28/12/1999

Launch date

22/12/2000

Delivery date

08/06/2001

Builder

Astilleros Españoles SA (AESA)

Puerto Real

Spain

Yard number

C-86

Hull material

Steel

Hull type

Single hull - Double bottom

Watertight compartments

5

Main engine

4x Wärtsilä 8L46A - 4 stroke single action 8 cylinder 460×580 mm combustion engines each 7.240 kW at 500 rpm

Total 28.960 kW / 39.348 hp

Built: 2000

Builder: Wärtsilä Iberica S.A., Bermeo (Vizcaya) - Spain

Note: Coupled in pairs, by a flexible coupling, a gear shaft and its corresponding queue

Propellers

2x Lips screw propeller controllable pitch- aft at 183 rpm

Diameter 4.600 mm - 4 blades

Boilers

2x CHR Aalborg 271,00 m² - 9,0 bar

1x CHO Aalborg 269,00 m² - 9,0 bar

1x CHO Qingdao Goyo 295,00 m² - 7,0 bar

Electric installations

Power voltage: 400 V

Lighting voltage: 220 V

Frequency: 50 Hz

Shaft generator

2x Leroy Somer LSAM53M85 C6/6 AREP generators each 1.962 kVA / 1.570 kW - 380 Volt / 50 Hz

Generators

• 3x Wärtsilä 20 - 9 cylinder combustion engines each 1.620 kW at 1.000 rpm connected with 3 Leroy Somer LSAM53M85 C6 / 6 AREP generator each 1.962 kVA - 380 V / 50 Hz

• 1x MAN Demp D2842LE301 - 12 cylinder combustion generatorset 514 kW at 1.500 rpm

Emergency generator

1x MAN D2866 LXE combustion generatorset 313 kVA - 250 kW - 367 hp at 1.500 rpm

Bow thruster

2x Rolls-Royce Marine 250 TV type controllable pitch thrusters at the bow 1.000 kW at 320 rpm

Diameter 1.880 mm

Access to the garage

Two doors / ramps aft

Length: 18,00 m (16,00 m and 2,00 m ramp nail)

Width: 8,50 m

Number of decks

10

Number of passengers decks

4

Number of passengers

972

Number of beds

748

Vehicle capacity

80 trucks and 336 cars

Tank capacities

Fuel oil: 804 m³

Diesel oil: 167 m³

Lubricating oil: 110 m³

Fresh water: 421 m³

Boiler feed water: 25 m³

Ballast water: 1.930 m³

Anti-heeling tanks: 673 m³

ISM & commercial manager

Acciona Trasmediterranea SA

planta 19, Paseo de la Castellana 259D

28046, Madrid

Spain

Operator

Acciona Tansmediterranea

Registered owner

planta 19, Paseo de la Castellana 259D

28046, Madrid

Spain

Renamed

02/2019 Ciudad Autonoma Melilla

Spain, Santa Cruz De Tenerife

• Manager: Acciona Trasmediterrane

• Owner: Acciona Trasmediterrane

04/2024 Fortuny

Spain, Santa Cruz De Tenerife - Call Sign: EBTO

• Registered owner: Trasmediterranea (CIA) S.A.

• c/o Compania Trasmediterranea SA, Madrid - Spain

• ISM & commercial manager: Acciona Trasmediterranea SA, Madrid - Spain

Latest data adjustment

19 April 2025
