Zeebrugge 09 October 2016 |
 |
 |
 |
 |
 |
 |
|||||
| Zeebrugge 09/10/16 | Zeebrugge 08/04/15 | Zeebrugge 08/04/15 | Zeebrugge 08/04/15 | Zeebrugge 08/04/15 | Zeebrugge 08/04/16 |
 |
| Zeebrugge 13/05/15 |
|
Name |
SPICA LEADER |
|
Type |
Roll-On/Roll-Off car carrier |
|
IMO-number |
9536909 |
|
Call sign |
9V9599 |
|
Flag |
Republic of Singapore |
|
Port of registry |
Singapore City |
|
GT |
41.886 t registered |
|
DWT |
Summer: 14.378 t |
|
NT |
12.566 t registered |
|
Length |
190,03 m overall |
|
Breadth |
28,20 m moulded |
|
Draught |
Summer: 9,33 m |
|
Moulded L x B x D |
182,00 x 28,20 x 14,32 m |
|
Registered L x B x D |
184,08 x 28,20 x 20,76 m |
|
Freeboard |
5.034 mm |
|
Depth |
14,32 m moulded |
|
Speed |
Max.: 21,1 knots Service: 19,5 knots |
|
Built |
2012 |
|
Keel laid |
19.12.2008 |
|
Launch date |
15.12.2011 |
|
Date of completion |
17.05.2012 |
|
Builder |
Shin Kurushima Onishi Shipyard |
|
Yard number |
5673 |
|
Hull material |
Steel |
|
Main engine |
1x Mitsubishi-Kobe Hatsudoki 7UEC52LSE - 2 stroke single acting 7 cylinder 520 x 2.000 mm diesel engine - 11.335 kW / 15.400 hp at 125,0 rpm Manufacturer: Kobe Diesel Co., Ltd. |
|
Propeller shaft |
1x Oil lubrication shaft with monitoring device Diameter: 625 mm |
|
Propellers |
1x Solid propeller |
|
Boilers |
1x Auxiliary vertical boiler - 7,9 bar Evaporation :2,91 t/h Manufacturer: Tortoise Engineering Co., Ltd. |
|
Generators |
4x Generators - 3.495 kW |
|
Bow thruster |
1x 1.100 kW |
|
Number of car decks |
10 |
|
Deck area |
36.432 m² |
|
Number of cars |
3.921 |
|
Stern ramp capacity |
80,0 t |
|
Stern ramp opening height |
8,60 x 5,80 m |
|
Stern ramp width |
8,00 m |
|
Stern ramp length |
35,00 m |
|
Tank capacities |
Fuel oil: 2.477 m³ Fresh water: 504 m² Water ballast: 7.057 m³ |
|
Crew |
21 |
|
Manager |
Wallem Shipmanagement Limited |
|
Operator |
NYK-Line |
|
Registered owner |
Spica Shipholding Pte. Ltd. |
|
Latest data adjustment |
25 April 2015 |
