Westerschelde 01 September 2015 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 22/10/15 | Westerschelde 18/02/14 | Antwerpen 07/05/19 | Vlissingen 10/05/15 | Vlissingen 10/05/15 | Vlissingen 10/05/15 | |||||
|
Name |
SUZUKA EXPRESS |
|
Type |
Roll-On/Roll-Off vessel - Vehicle carrier PCTC - Pure Car and Truck Carrier |
|
IMO-number |
9448073 |
|
Call sign |
3FZA5 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
Previous flag |
Philippines, Manilla - Call sign: DUCC |
|
GT |
43.810 t |
|
DWT |
Summer: 15.154 t |
|
NT |
13.143 t |
|
Length |
180,00 m overall |
|
Breadth |
30,00 m moulded |
|
Draught |
Summer: 9,22 m |
|
Moulded L x B x D |
171,70 x 30,00 x 13,10 m |
|
Registered L x B x D |
174,34 x 30,00 x 20,13 m |
|
Freeboard |
3.913 mm |
|
Depth |
13,10 m moulded |
|
Speed |
Trail: 21,8 knots Full speed: 19,9 knots Eco: 16,8 knots |
|
Built |
2010 |
|
Keel laid |
17/12/2008 |
|
Launch date |
20/10/2009 |
|
Date of completion |
26/02/2010 |
|
Builder |
Mitsubishi Heavy Industries Ltd. Shimonoseki Shipyard & Machinery Works Shimonoseki Japan |
|
Yard number |
1135 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Main engine |
1x Mitsubishi 8UEC50LS II - 2 stroke single acting 8 cylinder 500 x 1.950 mm combustion engine 11.560 kW / 15.707 hp at 127,0 rpm Manufacturer: Mitsubishi Heavy Industries, Ltd., Kobe Shipyard & Machinery Works - Japan |
|
Propeller shaft |
1x Oil lubrication shaft with monitoring device Diameter: 560 mm |
|
Propellers |
1x Screw propeller solid - aft at 127,0 rpm |
|
Boilers |
1x Auxiliary vertical boiler - 6,9 bar Evaporation: 2,05 t/h Manufacturer: Osaka Boiler Mfg., Co., Ltd. |
|
Generators |
3x Main diesel generatorsets each 1.125 kVA - 900 kW - 1.304 hp |
|
Emergency generator |
1x Diesel generatorset 125 kVA - 100 kW - 186 hp |
|
Bow thruster |
1x 1.200 kW |
|
Number of decks |
10 |
|
Deck area |
Deck 1: 2.070 m² Deck 2: 2.550 m² Deck 3: 2.720 m² Deck 4: 3.840 m² Deck 5: 4.180 m² Deck 6: 3.860 m² Deck 7: 4.640 m² Deck 8: 4.770 m² Deck 9: 4.730 m² Deck 10: 2.070 m² Total: 35.430 m² |
|
Number of cars |
3.930 RT 43 standard cars - 4.125 x 1,55 m |
|
Lift able decks |
2 |
|
Mobile deck lifter |
1 |
|
Number of ramp |
1x Stern ranp: 30,00 x 7,00 m - 100 t 1x Side ramp: 17,00 x 4,50 m - 15 t |
|
Tank capacities |
Fuel oil: 2.571 m³ Fresh water: 471 m² Water ballast: 7.291 m³ |
|
Manager |
Fleet Management Limited |
|
Operator |
Vroon Haven Westzijde 21 4511 AR Breskens The Netherlands |
|
Registered owner |
PCTC Express VIII B.V. Haven Westzijde 21 4511 AR Breskens The Netherlands |
|
Renamed |
01/2022 Siem Copernicus Republic od Singapore; Singapore City - Call sign: 9V7752 Owner: SY PCTC 3 Pte. Ltd. - Republic of Singapore |
|
Latest data adjustment |
03 March 2015 |
