Westerschelde 18 June 2016 |
 |
 |
 |
 |
|||
| Westerschelde 04/08/14 | Doel, Belgium 29/07/19 | Westerschelde 15/07/19 | Westerschelde 15/07/19 | |||
|
Name |
GLOVIS SUMMIT |
|
Type |
Roll-On/Roll-Off vehicles carrier |
|
IMO-number |
9702417 |
|
Call sign |
V7EL8 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
GT |
64.546 |
|
DWT |
20.056 t |
|
NT |
22.577 |
|
Length |
199,97 m overall |
|
Breadth |
35,00 m |
|
Draught |
10,02 m |
|
Reg. Dimensions L x B x D |
194,32 X 35,40 X 20,52 m |
|
Rule Dimensions L x B x D |
188,80 X 35,40 X 14,48 m |
|
Freeboard |
Summer: 3.220 mm |
|
Depth |
14,48 m moulded |
|
Speed |
20,15 knots |
|
Built |
2014 |
|
Keel laid |
16/12/2013 |
|
Launch date |
01/03/2014 |
|
Date of completion |
13/05/2014 |
|
Builder |
Hyundai Samho Heavy Industries Co., Ltd. Yeongam South Korea |
|
Yard number |
S-718 |
|
Hull material |
Steel |
|
Main engine |
1x HHI/MAN-B&W 7S60ME-C8 2 stroke single acting 7 cylinder 600 x 2.400 mm combustion engine 13.070 kW / 17.770 bhp at 102,0 rpm Built: 11/2013 Builder: Hyundai Heavy Ind. Engine & Machinery, Ulsan - South Korea |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary water tube boiler - 8,8 bar Heating surface: 30,2 m² 2x Economizer EGE boilers - 12,7 bar Heating surface: 483 m² Build: 10/2013 Builder: Kangrim Heavy Industrial Co., Ltd.,Changwon - South Korea |
|
Generators |
1x Generatorset 1.250 kVA / 450 Volt 2x Generatorset each 1.872 kVA / 450 Volt |
|
Number of cars |
7.300 |
|
Tank capacities |
Fuel oil: 3.452,20 m³ Fresh water: 320,70 m³ Water ballast: 9.230,80 m³ |
|
Crew |
24 |
|
Commercial manager |
Hyundai Glovis Co., Ltd. 83-21, Wangsimni-ro, Seongdong-gu Seoul South Korea |
|
Technical manager |
G-Marine Service Co., Ltd. 331, Jungang-daero, Dong-gu Busan, 48792 South Korea |
|
Registered owner |
Hyundai Glovis Co., Ltd. 83-21, Wangsimni-ro, Seongdong-gu Seoul South Korea |
|
Latest data adjustment |
29 April 2025 |
