| Zeebrugge 19 March 2009 |
 |
 |
 |
||
| Zeebrugge 08/03/09 | Zeebrugge 10/04/14 | Zeebrugge 10/04/14 |
|
Name |
GRAND PIONEER |
|
Type |
Vehicles Carrier |
|
IMO-number |
9247572 |
|
Call sign |
HOBN |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
58.947 t |
|
DWT |
Summer: 19.120 t |
|
NT |
17.685 t |
|
Length |
199,54 m overall 190,00 m between perpendiculars 192,85 m registered |
|
Breadth |
32,26 m overall |
|
Reg. Dimensions L x B x D |
192,85 x 32,26 x 23,82 m |
|
Rule Dimensions L x B x D |
190,00 x 32,26 x 34,06 m |
|
Draught |
Summer: 9,62 m |
|
Freeboard |
Summer: 5.014 mm |
|
Depth |
14,60 m |
|
Speed |
20,75 knots |
|
Built |
2002 |
|
Keel laid |
03.08.2001 |
|
Launch date |
27.12.2001 |
|
Date of completion |
17.04.2002 |
|
Builder |
Shin Kurushima Dockyard Co., Ltd. Onishi |
|
Yard number |
H-5136 |
|
Hull type |
Single hull |
|
Bulkheads |
6x Watertight |
|
Main engine |
1x Mitsubishi - 2 stroke single acting 8 cylinder 600 x 2.200 mm engine - 14.160 kW at 100,0 rpm Built: 09.2002 Place of manufacturer: Kobe - Japan |
|
Propulsion type |
1x Single screw diesel engine |
|
Boilers |
Boiler makers: Tortoise Engineering Co., Ltd. Date of manufacturer: 07.2001 |
|
Generator |
4x Main diesel generatorsets each 1.200 kVA - 450 V |
|
Tank capacities |
Ballast: 7.915 m³ Freshwater: 402 m³ Fuel oil: 1.757 m³ |
|
Number of decks |
13 |
|
Car capacity |
6.500 |
|
Crew |
20 |
|
Manager |
Cido Shipping (H.K.) Co., Ltd. Hong Kong |
|
Technical manager |
Cido Shipping (South Korea) Co., Ltd. (Pusan Site) |
|
Owner |
Dynamic Carrier Shipping S.A. |
