| Zeebrugge 08 September 2014 |
 |
 |
 |
 |
 |
||||
| Zeebrugge 08/09/14 | Zeebrugge 08/09/14 | Zeebrugge 08/09/14 | Zeebrugge 26/09/09 | Zeebrugge 26/09/09 |
|
Name |
COLUMBIA HIGHWAY |
|
Type |
Vehicles carrier |
|
IMO-number |
9442873 |
|
Call sign |
3EQO8 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
59.493 t registered |
|
DWT |
18.930 t |
|
NT |
19.244 t |
|
Length |
199,97 m |
|
Breadth |
32,26 m |
|
Moulded L x B x D |
192,00 x 32,26 x 14,70 m |
|
Registered L x B x D |
194,14 x 32,26 x 21,31 m |
|
Draught |
Summer: 10,017 m |
|
Freeboard |
Summer: 4.715 mm |
|
Depth |
34,8 m moulded |
|
Built |
2008 |
|
Keel laid |
04.10.2007 |
|
Launch date |
10.03.2008 |
|
Date of completion |
12.05.2008 |
|
Builder |
Imabari Shipbuilding Co., Ltd. Marugame Headquarters |
|
Yard number |
1472 |
|
Hull type |
Single hull |
|
Main engine |
1x Kobe diesel - 2 stroke single acting 8 cylinder 600 x 2.300 mm engine - 13.260 kW / 18.028 bhp at 100 rpm Manufacturer: Kobe Diesel Co., Ltd. |
|
Propeller |
1 |
|
Boiler |
1x Auxiliary vertical boiler - 7,8 bar |
|
Generators |
4x Main diesel generatorsets 4.700 kVA |
|
Car capacity |
Cars: 6.237 Trucks: 109 |
|
Tank capacities |
Fuel oil: 3.010 m³ Fresh water: 659 m³ Ballast water: 8.449 m³ |
|
Lifting capacity |
2x Cranes - SWL 0,5 t 3x Cranes - SWL 4,0 t |
|
Crew |
19 |
|
Manager |
Shoei Kisen Kaisha, Ltd. |
|
Operator |
K-Line |
|
Registered owner |
Los Halillos Shipping Co., S.A. |
|
Latest data adjustmnet |
09 October 2014 |
