Westerschelde 25 August 2015 |
 |
 |
|
| Westerschelde 25/08/15 | Westerschelde 24/11/17 | |
|
Name |
BOW SPRING |
|
Type |
Tanker for chemicals & Oil products |
|
IMO-number |
9215256 |
|
Call sign |
LADW6 |
|
Flag |
Norway |
|
Port of registry |
Bergen |
|
GT |
29.992 t Suez: 31.206 t Panama: 24.888 t |
|
DWT |
Summer: 39.942 t |
|
NT |
15.032 t Suez: 26.983 t Panama: 24.904 t |
|
Light ship |
14.472 t |
|
Length |
182,88 m overall 175,25 m between perpendiculars |
|
Breadth |
32,18 m extreme |
|
Draught |
12,45 m at deadweight summer |
|
Keel to mast |
46,63 m |
|
Depth |
17,94 m |
|
Speed |
14,6 knots |
|
Built |
2004 |
|
Keel laid |
13/08/2003 |
|
Launch date |
03/03/2004 |
|
Date of completion |
31/08/2004 |
|
Builder |
Stocznia Szczecinska Nowa Sp.z.o.o Szczecin Poland |
|
Yard number |
B588-III/3 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Bulkheads |
Transverse: 11 Longitudinal: 6 |
|
Main engine |
1x Wärtsilä NSD 6RTA58T-B - 2 stroke 6 cylinder 580 x 2.416 mm combustion engine 12.750 kW / 17.335 hp at 105 rpm Manufacturer: H. Cegielski, Poznan - Poland |
|
Propellers |
1x Rolls-Royce controllable pitch propeller |
|
Boilers |
2x Auxiliary boiler, oil/gas fired AQ-18 - 7,0 bar 1x Auxiliary boiler, exhaust gas heated AV-6 - 7,0 bar Builder: Aalborg Industries A/S |
|
Generators |
3x MAN-B&W 6L28/32H main diesel generatorsets each 1.260 kW / 1.740 hp at 720 rpm |
|
Emergency generator |
1x MAN D2866 E/TE/LE diesel generatorset 150 kVA |
|
Bow thruster |
1x 1.000 kW / 1.360 hp |
|
Number of tanks |
40 |
|
Cargo capacity 98% |
Total centre tanks: 20.286 m³ Total wing tanks: 28.716 m³ General total: 51.113 m³ |
|
Number of deck tanks |
6 |
|
Slop tank capacity |
1.138 m³ |
|
Pumps |
27x Cargo pumps each 230 m³/h 7x Cargo pumps each 330 m³/h 6x Cargo pumps each 100 m³/h |
|
Manifolds |
Summer draft to manifold: 8,72 m Rail to manifold: 4,85 m Bow to centre of manifold : 92,94 m |
|
Tank capacities |
Ballast: 16.676,4 m³ |
|
Anchor equipment |
Length: 660,00 m Diameter: 76 mm |
|
Crew size |
31 |
|
Commercial manager |
Odfjell Chemical Tankers AS Conrad Mohrs Veg 29 5072 Bergen Norway |
|
ISM manager |
Odfjell Management AS Conrad Mohrs Veg 29 5072 Bergen Norway |
|
Registered owner |
Odfjell Chemical Tankers AS Conrad Mohrs Veg 29 5072 Bergen Norway |
|
Latest data adjustment |
15 April 2024 |
