Bow Sirius 01

Westerschelde 04 July 2017



Name

BOW SIRIUS

Type

Chemical and product tanker

IMO-number

9215294

Call sign

LACQ7

Flag

Norway

Port of registry

Bergen

GT

29.965 t

Suez: 31.206 t

Panama: 24.888 t

DWT

Summer: 40.048 t

NT

15.032 t

Suez: 26.983 t

Panama: 24.903 t

Lightship

14.366 t

Length

182,88 m overall

175,25 m between perpendiculars

Breadth

32,21 m extreme

Draft

Summer: 11,52 m

Keel to mast

46,63 m

Depth

17,95 m

Speed

14,6 knots

Built

2006

Keel laid

23/09/2005

Launch date

17/06/2006

Date of completion

15/12/2006

Builder

Stocznia Szczecinska Nowa Sp.z.o.o.
Szczecin
Poland

Yard number

B588-III/7

Hull material

Steel

Hull type

Double hull

Bulkheads

Transverse: 11

Longitudinal: 6

Main engine

1x Wärtsilä 6RTA58T - 2 stroke 6 cylinder combustion engine 12.750 kW / 17.335 hp at 105,0 rpm

Propellers

1x Kamewa Ulstein controllable pitch propeller

Diameter: 6.800 mm

Boilers

2x Auxiliary boiler, oil/gas fired AQ-18

1x Auxiliary boiler, exhaust gas heated AV-6N
Manufacturer: Aalborg Industries A/S

Generators

3x MAN 6L28/32H main diesel engine each 1.500 kW coupled with AVK generators each 1.499 kVA

Emergency generator

1x MAN D2866 E/TE/LE diesel engine 218 kw coupled with AVK generator 250 kVA

Bow thruster

1x 1.000 kW

Number of cargo tanks

40

Number of segregations

40

Cargo tank capacity 98%

51.104 m³

Pumps

27x Framo cargo pumps each 230 m³

7x Framo cargo pumps each 330 m³

6x Framo cargo pumps each 100 m³

Manifolds

Summer draft to manifold: 8,70 m

Rail to manifold: 4,70 m

Bow to manifold: 92,94 m

Tank capacities

Ballast: 16.676,7 m³

Anchor equipment

Length: 664,50 m

Diameter: 76 mm

Accommodation

31 One man cabins

Manager

Odfjell Management AS

Technical manager

Odfjell SE

Conrad Mohrsv. 29

5892 Bergen
Norway

Operator

Odfjell Tankers

Owner

Nordic Leasing
Halifax
United Kingdom

Registered owner

Odfjell Chemical Tankers AS

Latest data adjustment

25 April 2018
