Name |
PATAGONIA |
|
Previous names |
2006 - 01/2011 Maersk Nairn |
|
Type |
Tanker for chemicals and oil products |
|
IMO-number |
9312080 |
|
Call sign |
CQEE6 |
|
Flag |
Portugal |
|
Port of registry |
Madeira |
|
Previous flags |
2006 - 2008 Cyprus 2008 Malta, Valletta - Call sign: 9HNL9 |
|
GT |
11.935 t |
|
DWT |
Summer: 16.772 t |
|
NT |
5.137 t |
|
Length |
144,16 m overall 133,80 m between perpendiculars |
|
Breadth |
23,03 m extreme |
|
Draught |
Max.: 8,90 m |
|
Keel to mast end |
44,50 m |
|
Freeboard |
3.511 mm |
|
Depth |
12,40 m |
|
Speed |
Max.: 14,0 knots |
|
Built |
2006 |
|
Keel laid |
21/12/2004 |
|
Launch date |
19/09/2005 |
|
Date of completion |
04/04/2006 |
|
Builder |
Jiangnan Shipyard (Group) Co., Ltd. China |
|
Yard number |
H2331 |
|
Hull material |
Steel |
|
Main engine |
1x MAN-B&W 6L48/60B - 4 stroke 6 cylinder 480 x 600 mm combustion engine 6.300 kW at 514 rpm Builder: MAN Diesel & Turbo SE |
|
Propellers |
1x Controllable pitch propeller Builder: MAN B&W Diesel A/S, Alpha Diesel |
|
Boilers |
1x Auxiliary boiler, composite Mission OC 1x Auxiliary boiler, oil/gas fired Mission OM Builder: Aalborg Industries A/S |
|
Shaft generator |
1x 1.875 kVA |
|
Generators |
1x Wärtsilä W4L20 diesel generatorset 1.080 kW 2x Wärtsilä W6L20 diesel generatorsets each 1.620 kW Total capacity: 2.800 kVA Builder: Wärtsilä Finland Oy |
|
Emergency generator |
1x Sisu 634 diesel generatorset 125 kVA / 158 kW Builder: AGCO Sisu Power, GenPowex |
|
Bow thruster |
1x 750 kW |
|
Number of cargo tanks |
12 + 2 slop tanks |
|
Cargo tank capacity |
19.052 m³ |
|
Number of pumps |
12x Cargo pumps each 300 m³/h Total unloading capacity: 2.100 m³/h |
|
Tank capacities |
Ballast: 8.180 m³ IFO: 580,3 m³ MGO: 74,8 m³ |
|
Anchor equipment |
Length: 577,50 m Diameter: 58 mm |
|
Crew size |
20 |
|
ISM & commercial manager |
Harren Tanker Management GmbH & Co. Hermann-Hollerith-Strasse 10 28355 Bremen Germany |
|
Registered owner |
58. PHOENIX PCT UG (haftungsbeschränkt) & Co. KG MS "NEPTUN" 49733 Haren (Ems) Germany |
|
Latest data adjustment |
27 November 2022 |
